Help Center3NB-1300 DRILLING MUD PUMP
Related Products
Specifications
1.MAX INPUT:970KW2.MAX SPEED:120SPM
3.STROKE:305MM
4.DISPLACEMENT:51.8L/S
5.RATED PRESSURE:35MPA
3NB-1300 drilling mud pump is the pump researched and manufactureed by Qingzhou petroleum machinery factory . The design characteristics is an optimization parameter, it can increase the stroke properly, lower the speed reasonably, improve the suction capability of the pump, and prolong the service life of wearing parts .The pump is used for oil-field and other industrial and mining establishments; and also used for the drill, well workover and transporting the liquid media.it is mainly installed on 25-45 rig.
The series pump are produced according to SY5138 of the petroleum industry standard strictly, and carry through factory's experiment according to the standard.
3NB1300 Drilling mud pump technical parameter
|
Type |
Triplex Single Acting Piston Pump |
Stroke Length: |
305 mm |
|
Rated power |
1300HP 956KW |
Suction inlet |
Φ300 mm |
|
Rated speed |
120 SPM |
Discharge outlet |
Φ102 mm |
|
Gear ratio |
4.194
|
Weights |
26800 Kg |
|
Pump Speed (SPM) |
Liner Size (mm) |
||||||||
130 |
140 |
150 |
160 |
170 |
180 |
||||
Theoretical Displacement (L/s) | |||||||||
120 |
24.27 |
28.16 |
32.52 |
36.18 |
41.52 |
46.54 |
|||
100 |
20.23 |
23.46 |
27.1 |
30.15 |
34.6 |
38.78 |
|||
90 |
18.21 |
21.12 |
24.39 |
27.13 |
31.14 |
34.90 |
|||
|
MPa Pressure Rating |
34.3 |
30.5 |
26.6 |
23.4 |
20.7 |
18.5 |
|||
To get more information, pls contact with me by skype: c.xcindy
