3G W-CDMA Repeater Signal Booster WCDMA 2100Mhz Mobile Phone Signal Repeater Amplifier
Mobile Phone Signal Repeater
A mobile phone signal repeater provides the ultimate solution in any area where cellular communications can not work well due to leak of signal.. The repeater device features easy installation & operation, build-in indoor antenna and no interference. It would also improve indoor electromagnetism environments.
Protect cellular battery life and reduce radiation of cellphones.
A mobile phone repeater is deal for house and office use.
Features:
High gain, easy installation and operation
Full-duplex, single-port design
Use ALC technology. Adjust extent automatically
LED indictor and signal condition indicators
Big linear power, control intermediation and saturation stably
Depend ability stand by Gb6993-86 standard
CE and ROHS approved
High points:
1. Enhance mobile phone signal strength
2. Improve cellphone quality
3. Reduce cellphone radiation
4. Protect the cellular battery life
5. Economic building cost
6. Easy operation
7. Easy installation
8. Build-in power supply
Item |
Specification |
|
Uplink |
Downlink |
|
Frequency |
1920-1980MHz |
2110-2170MHz |
Power |
-70~ 40dbm/FA (1.23MHz) |
|
Gain |
55db |
60db |
Max Output Power |
+17dbm/Total power |
+17dbm/Total power |
Impedance |
50ohm |
|
Seclusion |
>70db |
|
Power Supply |
AC110-220V (Use AC/DC Adapter 5V dc) |
|
Compact Design |
Indoor use |
|
Item Dimension |
100 * 45 * 17 mm |
|
Installation Approaches:
- Fix up outdoor antenna on the housetop and point to the signal tower.
- Connect the outdoor antenna on “ outdoor” port of repeater through cable.
- Connect indoor antennas to “indoor” port in repeater machine through cable.
- Plug power adapter into AC power socket and finish installation.
Installation Approaches:
- If the no signal receipt after activated repeater. Please check if outdoor antenna point to signal tower or elsewhere have strong signal and check if strength achieve 70dbm
- If cannot call not. Please adjust the direction of outdoor antenna. If strength is not steady, please check if outdoor and indoor antennas are too close. Please ensure the outdoor and indoor antenna has distance of 20m at least, with a wall between and in a same horizontal line.
Accessories section:
Outdoor antenna use 7 unit yagi type antenna, indoor antenna use board or rooftop antenna and signal wire use coaxial-cable.
