Good elasticity titanium medical bar for hip joint
Welcome to
----------------------------------
Baoji BoYang metal material Co.,LTD
The company is located in Baoji, the Titanium City of China. The company is mainly engaged in rare metals processing and machining. And it is also a special manufacturer of nonferrous material sales, products and equipment manufacturing and new products development. We have the followings as our major products and
it is with the design and manufacture at the core, such as shaped pieces, titanium plate, titanium bar, titanium wire GR1 GR2 GR3 GR5 GR7 GR9. Moreover, the company has titanium material, titanium standard parts, titanium composite material and other complete product line of nonferrous metal products. The products are widely used in chemical, metallurgy, petroleum, textile, medicine, light industry, environmental protection, sports, mining, marine and other fields. Relying on the strong industry resources, powerful scientific research, the ability to manufacture and a complete industrial chain of titanium industrial manufacturing of “the Titanium City of China", we are keep improving our sales service with our honesty and sincerity, and will do so. We warmly welcome both new and old clients to visit and negotiate with us.
------------------------------------------
Titanium Bar Advantage:
(1)Choose excellent raw material:0 grade Titanium sponge;
(2)Extremely Strict melting:3 time vacuum melting,Sampling,Flaw detection,Remove the head and bottom;
(3)Accurate tolerance:100% turbine through checking,ensure h7,h6 tolerance;
(4)Good straightness:0.3%o~0.5%o;
(5)100% ultrasonic/turbine flaw detection:100% Eliminate metallurgical defects and non-ferrous impurities;
(6)Stable mechanica property:The tensile strength of diameter below 20mm can be stably controlled at 1100(+/-)MPa;
(7)Stable and uniform microstructure:A1~A2.
| item | Titanium bar,titanium rod |
| Standard | GB/T2965-2007,JIS H4650-2001,ASTM B348-06,DIN17862-93,ASTM F136, AMS4928,GB/T13810,Q/BS5331-91,etc |
| Diameter | 1-350mm |
| Length | 50-6000mm |
| Surface | Black,polish,brush,hair line,etc |
| Package | Standard export package ,by wooden box ,or as required |
| Application | Titanium bar Is mainly used in machinery and equipment, electroplating equipment, medical and all kinds of precision parts and other industries |
| MOQ | 100Kg |
| Export to | Iran,India,Russia,Spain,Egypt,Korea,Thailand,Holland,Brazil,USA,Saudi Arabia, South Korea,Singapore,Indonesia,Kuwait,Canada,Chile,Viet Nam,etc |
| Contact | If you have any question,pls feel free to contact me . We are sure your inquiry and requirements will get prompt attention. |
| Element | Composition | |||||||||
| Gr1 | Gr2 | Gr3 | Gr4 | Gr5 | Gr6 | Gr7 | Gr9 | Gr11 | Gr12 | |
| C% | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 |
| H% | ≤0.015 | ≤0.013 | ≤0.015 | ≤0.015 | ≤0.05 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 |
| Fe% | ≤0.20 | ≤0.25 | ≤0.30 | ≤0.50 | ≤0.40 | ≤0.50 | ≤0.30 | ≤0.25 | ≤0.20 | ≤0.30 |
| N% | ≤0.03 | ≤0.03 | ≤0.05 | ≤0.05 | ≤0.03 | ≤0.03 | ≤0.03 | ≤0.03 | ≤0.03 | ≤0.03 |
| 0% | ≤0.18 | ≤0.25 | ≤0.35 | ≤0.40 | ≤0.20 | ≤0.20 | ≤0.25 | ≤0.15 | ≤0.18 | ≤0.25 |
| Ti% | balance | balance | balance | blance | balance | balance | balance | balance | balance | balance |
| Al% | / | / | / | / | 5.5-6.75 | 4.0-6.0 | / | / | / | / |
| V% | / | / | / | / | 3.5-4.5 | / | / | / | / | / |
Mechanical Property of Titanium Bar
Grade |
Tensile Strength , min |
Yield Strength,0.2% Offset |
Elongation,min,% |
Reduction of Area , min , % |
|||
Ksi |
Mpa |
Ksi |
Mpa |
|
|
||
Grade 1 |
35 |
240 |
20 |
138 |
24 |
30 |
|
Grade 2 |
50 |
345 |
40 |
275 |
20 |
30 |
|
Grade 3 |
65 |
450 |
55 |
380 |
18 |
30 |
|
Grade 4 |
80 |
550 |
70 |
483 |
15 |
25 |
|
Grade 5 |
130 |
895 |
120 |
828 |
10 |
25 |
|
Grade 7 |
50 |
345 |
40 |
275 |
20 |
30 |
|
Grade 9 |
90 |
620 |
70 |
483 |
15 |
25 |
|
Grade 12 |
70 |
483 |
50 |
345 |
18 |
25 |
|
------------------------------------------------------------------
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Baoji City, Shaanxi Province, China, about 2 hours train from Xi'an.
All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:How can I get some samples?
A: We are honored to offer you samples.
4.Q:How does your factory do regarding quality control?
A:Quality is priority. Hanz people always attach great importance to quality controlling from
the very beginning to the very end.
The first is the raw materials and strict control of spindle the second production process control, the third is the inspection factory.
Why Choose US
-------------------------------------------------
1.Provide free samples.
2.Fast delivery.
3.Guarantee quality.
4.High response rates.
5.Long time maintenance service the product.
6.Terrific after-sales service :24 hours around and 12 month warranty
Wish you success in your work!
=====================================
