Home > Electrical & Electronics > Sensor > Pressure Sensor > High Power Ultrasonic Transducer

High Power Ultrasonic Transducer

High Power Ultrasonic Transducer thumbnail-1
High Power Ultrasonic Transducer thumbnail-2
High Power Ultrasonic Transducer photo-1
High Power Ultrasonic Transducer photo-2
US$ 20 - 100 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Sinoder
Model Number:
SNHV-J01
Contact Supplier Request Quote Chat Now
Zhengzhou Sinoder Indutech Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name Sinoder
Model Number SNHV-J01
Usage Other, weighting
Theory Resistance Sensor
Output Analog Sensor



high power ultrasonic transducer





Parameter



Model

SNHV-J01

Rated capacities(Emax)

1,2,3,5,10,15,20,25,30,40t

Sensitivity

2.0±0.002 mV/V

Total error

±0.1,±002 percentF.S

Creep(30min)

±0.03 percent
F.S

Zero balance

±1 percent
F.S

TCO

±0.02 percent
F.S/10℃

TC SPAN

±0.02 percent
F.S/10℃

Input resistance

750 ±10 Ω(ohms)

Output resistance

703± 2 Ω(ohms)

Insulation resistance

≥5000MΩ

Temperature range,compensated

-10~+40℃

Temperature range,operating

-30~+70℃

Maximum safe overload

150 percent
F.S

Ultimate overload

300 percent
F.S

Excitation,recommend

10~12 V DC

Excitation,maximum

15 V DC

Protection Class

IP67

Construction

Alloy Steel



Cable

Length:8m(1~15t),10m(20t), 12m(25t)
14m(30,40t)
Diameter:5mm(1~5t)6mm(10~40t)





high power ultrasonic transducerhigh power ultrasonic transducerhigh power ultrasonic transducerhigh power ultrasonic transducer






high power ultrasonic transducer
