Help CenterGB 1-type Steel Wire Braided Hose
Related Products
-
GB-II High-pressure Steel Wire Braided HoseUS$ 1.5 - 15MOQ: 100 Pieces -
SAE Type II Steel Wire Braided HoseUS$ 1.5 - 15MOQ: 100 Pieces
-
Two-story or Four-Wire Spirally-would High Pressure HoseNegotiableMOQ: 100 Pieces
-
Dedicated Hose for WasherNegotiableMOQ: 1 Set
-
Pneumatic Pick TubeNegotiableMOQ: 100 Pieces
The Specification of GB 1-type steel wire braided hose:
DN |
Ram |
Wire OD |
O.D. |
Designed pressure |
Min Burst pressure |
Min bending radius |
|||
Min |
Max |
Min |
Max |
Min |
Max |
||||
mm |
mm |
mm |
mm |
mm |
mm |
mm |
MPa |
MPa |
mm |
5 |
4.5 |
5.4 |
8.9 |
10.1 |
11.9 |
13.5 |
25 |
100 |
90 |
6.3 |
6.1 |
6.9 |
10.6 |
11.7 |
15.1 |
16.7 |
22.5 |
90 |
100 |
8 |
7.7 |
8.5 |
12.1 |
13.3 |
16.7 |
18.3 |
21.5 |
86 |
115 |
10 |
9.3 |
10.1 |
14.5 |
15.7 |
19.0 |
20.6 |
18 |
72 |
130 |
12.5 |
12.3 |
13.5 |
17.5 |
19.1 |
22.2 |
23.8 |
16 |
64 |
180 |
16 |
15.4 |
16.7 |
20.6 |
22.2 |
25.4 |
27.0 |
13 |
52 |
205 |
19 |
18.6 |
19.8 |
24.6 |
36.2 |
29.4 |
31.0 |
10.5 |
42 |
240 |
25 |
25.0 |
26.4 |
32.5 |
34.1 |
36.9 |
39.3 |
8.8 |
35.2 |
300 |
31.5 |
31.3 |
33.0 |
39.2 |
41.7 |
44.5 |
47.6 |
6.3 |
25.2 |
420 |
38 |
37.7 |
39.3 |
45.6 |
48.0 |
50.8 |
54.0 |
5.0 |
20 |
500 |
51 |
50.4 |
52.0 |
58.7 |
61.9 |
65.1 |
68.3 |
4.0 |
16 |
630 |
Structure:
Rubber hose use synthetic cement which good in oil-proof and waterproof as hose lining;two layer of high-strength steel wire braided layer as the reinforcing layer. Let synthetic coment which good in oil-proof and resistance to weather aging as outer layer.
Application:
Suitable for coal industry integrated mining machinery and machinery Industrial Hydraulic Equipment.
It can transport a certain pressure hydraulic fluid,such as alcohol,hydraulic oil,fuel oil,lubricating oil,
emulsion,hydrocarbons.
Operating temperature range according to different working media are dividing into:
Hydraulic oil,fuel oil,lubricating oil -40~+50°C
Water,emulsion below +80°C
Carried standard:ISO1436/GB3683 1 model.
