Guangzhou CCTV Camera Monitoring Equipment Turbo HD1080P EXIR Dome Camera GSMAC20010

US$ 1 - 800 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

GSMAC20010

Type:

Analog Camera

Guangzhou SM International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number GSMAC20010

Type Analog Camera

Style Dome Camera

Sensor CMOS

Special Features Waterproof / Weatherproof

Specifications

1. HD1080P video output
2.Competitive price
3.IP66 weatherproof
4..Accept small order
5. Up the Coax(via coaxial cable)

Guangzhou CCTV camera Monitoring equipment Turbo HD1080P EXIR Dome Camera GSMAC20010

Product Description

GSMAC20010

Camera

Image Sensor:	1/3" Progressive Scan CMOS
Signal System:	PAL/NTSC
Effective Pixels:	1920(H)*1080(V)
Min. Illumination:	0.01 Lux @(F1.2,AGC ON), 0 Lux with IR
Shutter Time:	1/100 s to 1/100,000 s
Lens:	3.6mm (2.8mm, 6mm, 8mm optional) Angle of View: 80.9°(3.6mm), 103.5°(2.8mm), 54.3°(6mm), 38°(8mm)
Lens Mount:	M12
Adjustment Range:	Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360°
Day& Night:	IR cut filter with auto switch
Wide Dynamic Range:	120dB
Video Frame Rate:	1080p@25fps/1080p@30fps
HD Video Output:	1 Analog HD output
Synchronization:	Internal Synchronization
Video Output:	1Vp-p Composite Output (75Ω/BNC)
S/N Ratio:	More than 52dB
Up the Coax:	Support

Menu

Camera ID:	On/off (15 characters, position programmable)
D/N Mode:	Color/ BW/ EXT
Auto White Balance:	Auto / Manual
Private Mask:	On/Off, maximum 8 zones
Motion Detection:	On/Off, maximum 4 zones
BLC:	On/Off
Anti-flicker:	On/ Off
Language:	English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic
Scene:	Indoor, Outdoor, Indoor1, LOW-LIGHT
Function:	Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM

General

Operating Conditions:	-20 °C - 60 °C (-4 °F - 140 °F) Humidity 90% or less (non-condensing)
Power Supply:	12 V DC±10%
Power Consumption:	Max. 4W
Weather Proof:	IP66
IR Range:	Up to 20m
Dimension:	Φ114.6 × 89.1mm(Φ4.5” × 3.5”)
Weight:	300 g (0.66 lb)
