Specifications
widely used in power plant, chemical plant, real estate, subway, tunnel, etcdurable(usually more than 30 years' service time
Application
1. suitable for telecom cable device
2. thermocouple cable and other control cable device
3. universally used in telecom industry
4. any environment that need to be closed
Advantage
Full closed cable tray
1. dust proofing
2. tamper proofing
3. high load bearing
Surface finishing
1. hot dipped galvanized A. the thickness of zinc coating is above 350g/m B. mainly used outdoor electric projects with high humidity C. corrosiveness resistance
2. electrostatic spraying A. any color you can choose, good-looking B. mainly used indoor electrical projects C. corrosiveness resistance
3. electrolytic zinc plating
Dimensions
NO. |
MODEL |
SPECIFICATIONS(mm) WIDTH*HEIGHTH |
BODY WEIGHT(kg) |
COVER WEIGHT(kg) |
1 |
C-01A-1 |
50*25 |
7.9 |
2.9 |
2 |
C-01A-2 |
100*50 |
13.2 |
4.3 |
3 |
C-01A-3 |
150*75 |
18.7 |
7.5 |
4 |
C-01A-4 |
200*100 |
28.3 |
9.4 |
5 |
C-01A-5 |
250*125 |
32.1 |
12.3 |
6 |
C-01A-6 |
300*150 |
42.0 |
13.2 |
7 |
C-01A-7 |
400*200 |
65.5 |
19.9 |
8 |
C-01A-8 |
500*200 |
78.4 |
24.5 |
9 |
C-01A-9 |
600*200 |
109.4 |
34.8 |
10 |
C-01A-10 |
800*200 |
132.3 |
48.5 |
l customized
