Help CenterD250 X 550 Precision Mini Lathe
Related Products
1.Product Description
The bench lathe is a small size gear-driven DIY lathe. The type of machine features change speed by gear compact structure, beautiful design, easy operation and installation, low cost, etc. This machine is used in shaft and sleeves for turning internal and external surface, facing slotting and turning metric, inch thread, drilling. It can be widely used for enterprises standard to make moulds for all kinds of institutions to make moulds and school training, especially for household manufacturing and maintaining daily utensils and art works.
| Model | D250×400 |
D250×550 |
Max. swing over bed |
250mm |
250mm |
Distance between centers |
400mm |
550mm |
Spindle bore |
21mm |
21mm |
Taper of spindle bore |
MT3 |
MT3 |
Rang of spindle speeds(6 steps) |
125-2500rpm |
125-2500rpm |
Taper of tailstock quill |
MT2 |
MT2 |
Metric threads can be cut |
0.4-3mm |
0.4-3mm |
Inch threads can be cut |
10-44TP1 |
10-44TP1 |
Motor power |
0.6KW |
0.6KW |
NW/GW |
112/143Kg |
115/145Kg |
Package size(L×W×H) |
1050×560×580mm |
1200×560×580mm |
2.Machine Photo
3.Manufacturing Ability
