Racking Upright Roll Forming Machine
Automatic cable tray roll forming machine,this Full line is controlled by PLC control system with touch screen operation to achieve the human and PLC interactive.
The operator can monitor the setting program (programmable control) and modify the parameter
to control the line. Also can check the running status, parameter and error indication etc...
Operation type: manual /auto two type switch. In manual position: can run the each part of the
machine. In auto position: can run the full line. The emergency stop ensures the safe of the
equipment and operator.
Automatic Cable Tray Roll Forming Machine side is equipped with the manual operation control panel for convenient worker to operate
I: Composition of Machine
- Hydraulic Decoiler ------------------------------------------ 1 Unit
- Leveling and Feeding Guide -------------------------------- 1 Unit
- Punching Device ------------------------------------------- 1 Unit
- Roll Forming Machine -------------------------------------- 1 Unit
- Hydraulic Cutting ------------------------------------------ 1 Unit
- Hydraulic Station ------------------------------------------ 1 Unit
- PLC Contol System ---------------------------------------- 1 Unit
- Runout Table ---------------------------------------------- 1 Unit
- Spare Coupling -------------------------------------------- 1 Unit
II:Technical Data Of Automacit Cable Tray Roll Forming Machine
- Material Thickness:0.8-2.5mm
- Forming Station: 20--24stations
- Principal Axis Diameter: 65mm
- Line speed with punching: 3-6M/min
- Main Power: 15KW
- Leveling Power: 4*5.5KW
- Hydraulic Power: 7.5KW
- Gearbox deiven
- Dimension of Machine: 13.2M X1.2 MX1.2M ( LXWXH )
- Gross Weight of Machine: about 17Ton
- Voltage: 380V, 3 Phase 50Hz
III: Working Flow
Decoiler ---> Feeding ---> Main automatic cable tray Roll Forming ---> Cutting to Length ---> Runout Table
The profile:(Basis on customer’s require to design)
