Brazil GSM Cellphone Repeater 2G 850mhz Repeater
1,Waterproof cabinet suitable in outdoor and indoor
2,Both normal waterproof box and die-casting cabinet are available
3,Pole-installation, Wall-installation and Tower-installation are available
4,Cavity filter and IF SAW gives higher isolation, better gain flatness, higher stability, and lower noise figure;
5,Allowing for continuous gain adjustment and gain contrast;
6,ALC technology used to provide auto amplitude fixing.
7,Press-key , Local PC GUI and remote GSM MODEM management
Technical Specification:
Main Item |
Brazil GSM Cellphone Repeater 2G 850mhz Repeater |
||
Up Link |
Down Link |
||
Frequency Range |
824-849MHz |
869-894MHz |
|
Band width |
25MHz |
||
ALC |
Output increment will not exceed 2dB when input increase 20dB |
||
Frequency Error |
0.5ppm |
||
Gain Control Range |
0~30dB |
||
RF Output Power |
37dBm |
40dBm |
|
Gain |
90dB |
95dB |
|
Noise Figure |
5dB |
||
Group Delay |
1.5us |
||
IMD3 |
In-band |
-50dBC/30KHz |
|
Out-band (0ff 2.5MHz) |
-36dBm/30KHz,9KHz-1GHz |
||
-30dBm/30KHz,1GHz-12.75GHz | |||
Out-band Rejection |
-40dB ± 2.5MHz |
||
-60dB ± 10MHz | |||
Spurious emission |
-36dBm/30KHz,9KHz-1GHz |
||
-30dBm/30KHz,1GHz-12.75GHz | |||
VSWR |
1.5 |
||
Power Supply |
110VAC/220VAC/-48VDC/+24VDC |
||
Size |
465mmx310mmx215mm |
||
Weight |
About 18Kg |
||
Work temperature |
-40~+55 or -25~+65 |
||
Relative humidity |
95% |
||
Operation Configuration |
LCD Display, Manual Key-press |
||
Local RS232 Port | |||
Others |
Refer to user manual for more specification |
||
Kingtone
Since 2006, Kingtone has been developing and manufacturing Repeaters included CDMA Repeater, GSM Repeater,DCS Repeater, PCS Repeater, UMTS(W-CDMA) Repeater, Tetra Repeater, iDEN Repeater, Wimax Repeater and 4G LTE Repeater etc. Moreover, Kingtone Repeater have different types included Full Band-selective Repeater, Channel-selective Repeater, Frequency-shifting Repeater, Fiber-optical Repeater, Trunk-amplifier etc. The repeaters can be Single-band Repeater, Dual-band Repeater and Tri-band Repeater etc. The Multiple Bands for different Mobile Operators.
As well as the repeater, the passive circuits such as Power Splitters, Directinal Couplers, POI, Connectors, Antennas etc. are in operation.
At Present, Kingtone exhibited the highest quality products and enterprise’s comprehensive strength. And Kingtone continues to strengthen technological innovation on repeater products and will launch the new products on the market soon.
With your supports and new requirements which can make us improve our service, innovative our technology and consummate the products.
OEM & ODM are welcome!
Product range: GSM / CDMA / DCS / WCDMA / TETRA / LTE Wireless Full Band Repeater, Fiber Optic Repeater, Frequency Shifting Repeater, Digital / Analog Repeater, Trunk Amplifier
Support System |
Frequency Range |
Output Power |
GSM900MHZ |
890-915MHz/935-960MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
DCS1800MHz |
1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
PCS1900MHz |
1895-1910MHz/1975-1990MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA450MHz |
450-457.5MHz/460-467.5MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA800MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA1900MHz |
1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS2100MHz |
1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM900/1800MHZ |
890-915MHz/935-960MHz 1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/ |
GSM850/1900MHZ |
824-849MHz/869-894MHz 1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W |
GSM900/UMTS2100 |
890-915MHz/935-960MHz 1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/ |
Our present manufacturing service:
1. Single-band repeaters of LTE/GSM/CDMA/PCS/DCS/WCDMA
2. Dual-band repeater of GSM/DCS; GSM/WCDMA; CDMA/PCS;
3. Tri-band repeater of GSM/DCS/WCDMA
4,Trunk Amplifier
5. All kind of Antenna/Splitter/Connector/Cable
|
Anna Yao
|
|
Quanzhou Kingtone Optics & Electronics Technology Co., Ltd
Add:3th Floor,Bld B,Yucheng Base, Keji Road,Fengze district ,Quanzhou ,Fujian,China.
|
|
Tell: +86 595 28857992 Fax: +86 595 22155502 Whatsapp: +86 13178207380 skype: anna.yao696 Web: |
For more details of Brazil GSM Cellphone Repeater 2G 850mhz Repeater ,welcome you to contact us now!
If you'd like this product, click below and send your inquiry, we will back you the price list in 24hours!
