Specifications
Suitable for processing the flat-end bags with tub-size filmsComputer control, easy operation
Item: Automatic Three-folding Bag Making Machine
Model: DL-3Z800
Features: 1. This type of machine is suitablt for processing the flat-end bags with tub-size films of HDPE,LDPE in primal color or colors. Folding big one into the size of common bag.
2. There are two styles of electrical machine to support, one is step-in electric machine controlled by computer, and the other is imported servo machine. With PLC control, touch screen control panel, the peration is more convenient.
3. The height of the bags' after folding is exact and no need to coordinate by hand. Exactness for controlling of entering the material, without mistake for material breaking off.
4. The machine can fold the flat-end bag thrice and change the bigh bags into small one.
Main technical parameters:
Model |
DL-3Z800 |
Max. Bag Width |
700mm |
Max. Bag Length |
650-1000mm |
Bag Thickness |
0.01-0.1mm |
Speed |
30-50(pcs/min.) |
Total Power |
3.5(kw) |
Size |
4.2*1.3*1.6m |
Weight |
~1700kg |
