The LDPE film blowing machine
The film blowing machine/film blowing machines/film blowing machinery/plastic film blowing machinery is used to produce the mulch plastic film, agricultural film and outer
package film made of low density polyethylene (LDPE), high density polyethylene
(HDPE), linear low density polyethylene (LLDPE) and metallocene linear low density
polyethylene (LLDPE). This kind of film blowing machines employs some new technologies like the most advanced heat running technology and special wind ring that is used to extrude the shaped
mulch plastic film. The film blowing machines is designed reasonably and elegantly. It is
small and is easy to operate and maintain. The product features with good
plasticization, high physical and mechanical performance and strong tear resistance.
SJ50-FMS850P film blowing machine
Features:
1) This film blowing machines is designed to produce plastic film made of low density polyethylene (LDPE), high density polyethylene (HDPE), linear low density polyethylene (LLDPE).
2) The pe film blowing machine is designed reasonably and elegantly. It is small and is easy to operate and maintain.
3) With high output, low energy consumption, good stability and reliability.
4) The film are widely used in application of package of civil and industrial products such as food, garment, textile and daily necessities etc. It includes vest bag, shopping bag, garment bag and food bag.
Machine Technical Parameters: | ||||||
MODEL NO. |
SJ45-FMS650P |
SJ50-FMS850P |
SJ55-FMS1100P |
SJ65-FMS1300P |
||
LAYER NUMBER |
1 |
|||||
MAX.FILM WIDTH |
LD mm |
550 |
800 |
1050 |
1250 |
|
HD mm |
500 |
750 |
1000 |
1200 |
||
FILM THICKNESS |
LD mm |
0.015~0.10 |
0.020~0.15 |
0.020~0.18 |
||
HD mm |
0.006~0.07 |
0.006~0.10 |
0.015~0.10 |
0.015~0.12 |
||
OUTPUT |
LD Kg/h |
30 |
45 |
50 |
65 |
|
HD Kg/h |
25 |
32 |
40 |
50 |
||
RAW MATERIAL |
HDPE,LDPE,LLDPE |
|||||
EXTRUDER |
|
|||||
SCREW DIAMETER |
mm |
Φ45 |
Φ55 |
Φ55 |
Φ65 |
|
SCREW L/D |
28:1 |
28:1 |
30:1 |
25:1 |
||
HEATER CAPACITY |
kw |
8.9 |
10.7 |
10.7 |
13.2 |
|
DRIVING MOTOR |
kw |
11 |
15 |
18.5 |
22 |
|
DIE (ROTATING DIE IS OPTIONAL): |
|
|||||
DIE DIAMETER (LD&HD FREE CHOICE) |
mm |
LDPE Φ 150 |
LDPE Φ 200 |
LDPEΦ250 |
LDPEΦ300 |
|
HDPEΦ50Φ70 |
HDPEΦ60Φ80 |
HDPEΦ60Φ90 |
HDPEΦ80Φ110 |
|||
HEATER CAPACITY |
kw |
LDPE 4.0 |
LDPE 4.8 |
LDPE6.15 |
LDPE6.7 |
|
HDPE: 3.45 |
HDPE: 3.45 |
HDPE: 3.45 |
HDPE: 6.1 |
|||
COOLING AIR BLOWER |
kw |
1.5 |
2.2 |
3 |
3 |
|
HAUL-OFF: |
|
|||||
DRIVING MOTOR |
kw |
0.75 |
1.5 |
|||
TAKE-UP SPEED |
m/min |
10~70 |
||||
WINDER DRIVE MOTOR |
kw |
4 |
4.5 |
|||
TEMPERATURE CONTROL |
point |
5 |
6 |
|||
WHOLE POWER WITH TOTAL MACHINE |
kw |
~35 |
~42 |
~50 |
~62 |
|
SHAPE SIZE |
m |
4.5X2.3 X 4.0 |
5.2 X 2.5X 4.0 |
5.5 X2.8 X 4.5 |
6.3 X3.0 X 5.0 |
|
WEIGHT |
t |
~2.5 |
~3.0 |
~3.5 |
~4.2 |
|
