Rotary Die Head Auto Winder pe Plastic Film Blowing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rotary Die Head and Automatic Winder Film Blowing MachineNegotiableMOQ: 1 Set -
Rotary Die Head and Automatic Winder Plastic Film Extruder Blown/blowing MachineNegotiableMOQ: 1 Set
-
Latest Plastic pe Film Extrusion MachineNegotiableMOQ: 1 Set
-
Automatic Plastic Pe Blown Film ExtruderNegotiableMOQ: 1 Set
-
Plastic Film Blowing Machine With Rotary Die Head and Automatic WinderNegotiableMOQ: 1 Set
Condition
New
Application
Film
Plastic Processed
PE
Blow Moulding Type
Extrusion Blow Moulding
Automatic
Yes
Place of Origin
Fujian, China
Brand Name
Donghailong
Model Number
SJ65-FMS1300PG
Voltage
220-380v
Power(W)
62KW
Dimension(L*W*H)
7.3X3.5X 5.5m
Weight
4.8T
Certification
CE,SGS
Warranty
1 YEAR
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
HDPE/LDPE film blowing machinerotary die head
automatic single station winder
few labor force, little waste
high efficiency
FEATURES:
The plastic film blowing machine employs new technologies such as rotary die head and fully automatic sigle station winder.
It is featured by reasonable structure,few labor force,little waste,high efficiency and excellent auality etc
The film blowing machine is employed to produce plastic film made of low density polyethylene (LDPE),high density polyethylene (HDPE), linear low density polyethlene (LLDPE) and metallocene linear low density polyethylene (LLDPE).
The product
s are widely used in application of package of civeil and industrial procucts such as food,garment,textile and daily mecessities.
The products include vest bag,shopping bag,garment bag and food bag etc.
| Main Technical Parameters | ||||
| Model | SJ45-FMS650PG | SJ50-FMS850PG | SJ55-FMS1100PG | SJ65-FMS1300PG |
| Max. Folded Film Width | 550mm | 800mm | 1050mm | 1250mm |
| Film Thickness | 0.015~0.10mm | 0.020~0.15mm | 0.020~0.18mm | |
| Output | 30kg/h | 45kg/h | 55kg/h | 80kg/h |
| Raw Material | HDPE,LDPE,LLDPE | |||
| Screw Diameter | Φ45mm | Φ50mm | Φ55mm | Φ65mm |
| Screw L/D | 28:01:00 | |||
| Total Power of the Machine | ~35KW | ~42KW | ~50KW | ~62KW |
| Shape Size( L x W x H) | 5.5 X2.8X 4.2m | 6.2X 3.0X 4.8m | 6.5 X3.3 X 5.2m | 7.3X3.5X 5.5m |
| Weight (T) | ~3T | ~3.5T | ~4.2T | ~c |
| Correct specifications depend on the actual model all specifications are subject to change without prior notice! | ||||
