SJ-PG series film blowing machine(with single statin full-automatically winder) SJ45-FMS650PG
Features:
The blown film machine is employed to produce plastic film made of low density polyethylene (LDPE), high density polyethylene (HDPE), linear low density polyethylene (LLDPE) and metallocene linear low density polyethylene (mLLDPE). Its products including shopping bags, T-shirt bags etc.
Main technical parameters:
MODEL NO. |
SJ45-FMS650PG |
SJ50-FMS850PG |
SJ55-FMS1100PG |
SJ65-FMS1300PG |
|
LAYER NUMBER |
1 |
||||
MAX.FILM WIDTH |
LD mm |
550 |
800 |
1050 |
1250 |
HD mm |
500 |
750 |
1000 |
1200 |
|
FILM THICKNESS |
LD mm |
0.015~0.10 |
0.020~0.15 |
0.020~0.18 |
|
HD mm |
0.006~0.07 |
0.006~0.10 |
0.015~0.10 |
0.015~0.12 |
|
OUTPUT |
LD Kg/h |
40 |
55 |
70 |
100 |
HD Kg/h |
35 |
50 |
60 |
80 |
|
RAW MATERIAL |
HDPE,LDPE,LLDPE |
||||
EXTRUDER |
|
||||
SCREW DIAMETER |
mm |
Φ45 |
Φ50 |
Φ55 |
Φ65 |
SCREW L/D |
28:1 |
28:1 |
30:1 |
25:1 |
|
HEATER CAPACITY |
kw |
8.9 |
10.7 |
10.7 |
13.2 |
DRIVING MOTOR |
kw |
11 |
15 |
18.5 |
22 |
DIE:( Rotating die is optional) | |||||
DIE DIAMETER( LD&HD FREE CHOICE) |
mm |
LDPE Φ 150 |
LDPE Φ 200 |
LDPEΦ250 |
LDPEΦ300 |
HDPEΦ50Φ70 |
HDPEΦ60Φ80 |
HDPEΦ60Φ90 |
HDPEΦ80Φ110 |
||
HEATER CAPACITY |
kw |
LDPE 4.0 |
LDPE 4.8 |
LDPE6.15 |
LDPE6.7 |
HDPE: 3.45 |
HDPE: 3.45 |
HDPE: 3.45 |
HDPE: 6.1 |
||
COOLING AIR BLOWER |
kw |
1.5 |
2.2 |
3 |
|
HAUL-OFF: |
|
||||
DRIVING MOTOR |
kw |
0.75 |
1.5 |
||
TAKE-UP SPEED |
m/min |
10~70 |
|||
WINDER DRIVE MOTOR |
kw |
4 |
4.5 |
||
TEMPERATURE CONTROL |
point |
5 |
6 |
||
WHOLE POWER WITH TOTAL MACHINE |
kw |
~30 |
~36.5 |
~43 |
~52 |
SHAPE SIZE |
m |
5.5 X 2.8 X 4.0 |
6.2 X 3.0 X 4.0 |
6.5 X 3.3 X 4.5 |
7.3 X 3.5 X 5.0 |
WEIGHT |
t |
3 |
3.5 |
4 |
4.5 |
Pictures:
Sales services:
Train operators for the clients who have bought the products of our company.
Once a contracted product is finished, a blank-run test for 72 hours shall be done in the company.
The client may appoint his men to the company for a prelimimary acceptance check of the products(stress test) together with the technicians of the company before the products are delivered from the company.
During the period as the products are in installation or application in the client's factory,our factory may send technicians to help adjust and test the products upon the invitation by the client until they are placed in operation.
The stress test for the large sized wide-coverage plastic blowing machine set shall be performed also in our factory in one step before being placed in operation,which may give confidence to the clients.
Plan and design a complete unit of the production line for clients,provide clients with secondary device in a quickest way and implement a full set supply.
We are very pleased to cooperate with you to create our bright future.
