High Speed Automatic vertical wrapping machine
This is a vertical pouch form-fill-seal packaging machine which is used for packing machine is comprised by the following parts/components:Automatic Vertical Form/fill/seal packing machine ,Ten beads electronic weighing scale. Z type feeding device,Vibrating feeding hopper,Final products outgong conveyor,and Stand-up frame body.
High Speed Automatic vertical wrapping machine
1.The machine incluing Z model conveyor ,weigher ,main vertical packaging machine ,platform ,and finish product conveyor ,It can automatically do bag-forming, weighing ,dosing, gas-flushing, coding,cutting.
2.Be applicable for packing gain product,for instance,puff snack food ,potato chips ,crispy rice ,jelly ,candy ,apple chips ,dumpling ,smal cookies ,dry fruit ,melon seeds ,roasted seeds and nut ,medical material ,deep-frozen food ,etc.
3.Working states&operation messages shows in Chinese/English by touch screen,recipes can be saved.
4.Cutting position&we-tracking can be adjusted through touch screen during the continuous running.
5.Temperature controller is uesd,difference in temperature range is in 3 degree.Dentiform sealer to seal hard.
6.Airproof configuration is used,low noise,free dust,especially used to pack powdery.
model |
RL420 |
RL 520 |
Packing speed |
25-80bags/min |
25-70bags/min |
Pouch making size |
Bag making width:80-200mm Bag making length:80-300mm |
Bag making width:100-250mm Bag making length:100-350mm |
Filling range |
10-1200g |
50-2000g |
Packing material |
Wax.paper,cellophane, aluminium film |
Wax.paper,cellophane ,aluminium film |
Packing film width |
Max.200mm |
Max.250mm |
power |
10kw |
12kw |
Gross weight |
2500kg |
2870kg |
Wooden Case
1.Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing: a. Inside the machine put desiccant b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement
After-sale services for all the customers
a. Free training of machine installation, operation and maintenance will be provided;
b. Some spare parts will be sent together with the machine for free and some spare parts are always at favorable price for regular customers;
c.Technical support will be offered by call, email or video etc;
d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance.
High Speed Automatic vertical wrapping machine
Shanghai Target Industry Co., Ltd is the sales and service company for Shanghai SHINWEI Machinery Manufacturing Co., Ltd which is the first manufacturer to build the complete production line for depositing hard candies in China and has accumulated 40 years’ fabrication experience. It is also one of the leading and professional exporters in China by providing customers home and abroad with high quality confectionery, chocolate, biscuit and packaging machinery. Our machineries have been exported to East European, south America, middle east, southeast Asia.
As the first-class corporation for fabrication of confectionery, chocolate, biscuit and packaging machinery, Target Industry offers not only the advanced equipment with competitive and economical efficiency, but the whole solutions for the customer's demands also. We provide the design, production, assembly and commissioning work of small or medium confectionery and biscuit machines in accordance with the customer's specific requirements.
