Automatic Metal Can Body Welder
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Usage:
Metal Forming Machine, Can body making machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shantou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NEW DODO 650cans/min Can Body Making LineNegotiableMOQ: 1 Unit -
Fully Automatic Can Welding MachineNegotiableMOQ: 1 Set
-
Fully Automatic Can Making Production Line for Foods/aerosol/paints/beverage Can/containerNegotiableMOQ: 1 Set
-
Automatic Round Tin Cans Welding Machine for Food CanNegotiableMOQ: 1 Set
-
Automatic Can Packing MachinesNegotiableMOQ: 1 Set
Condition
New
Automatic Grade
Automatic
Place of Origin
Guangdong, China
Brand Name
NEW DODO
Model Number
NEW DODO-300
Voltage
380V
Power(W)
40kw
Dimension(L*W*H)
2200 X 2240 X 2080
Weight
3500kg
Certification
CE certificate
Warranty
1 year
After-sales Service Provided
Overseas service center available
Automatic Metal Can Body Welder
Product Description
Main Feature:
1.Equipped with human-computer-interface and PLC.
2.Adopt digital control technology
3.Auto.trace for copper string driving speed
4.New digital inverter for power supply
5.Full control for every operation steps
6.Radio control available
Speciflcations of the series NEW DODO-300 Full Automatic Bodywelders
| Type | New DODO-250 |
New DODO-300 |
|
| Welding speed | 40m/min. |
48m/min. |
|
| production speed | 200-250cans/min. |
250-300cans/min. |
|
| Welding point distance | 0.5-0.9mm |
||
| Overlap | 0.4mm |
||
| Can diameter | (202)52-(401)99mm | ||
| Can height | 60-180mm | ||
| sheet thickness | 0.16-0.3mm |
||
| Material | Tinplate, Ni plate |
||
| Tin coating | 5#-100# |
||
| Temper | T2.5-DR8 |
||
| Copper wire dia. | 1.38mm,1.5mm |
||
| Power | three phase, voltage:380V |
||
frequency:50Hz electric comsumpt:60Kw | |||
| Welding Power | Frequency |
120-390Hz |
120-390Hz |
| Out capacity | 25KVA |
40KVA |
|
| welding frequency | 200-360Hz |
||
| Cooling water | 500kpa, 12-18oC, 20L/min. |
||
| Compressed air | 550kpa,800L/min. |
||
| Dimensions | 2200 X 2240 X 2080 |
||
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2004
Factory Size
5,000-10,000 square meters
Total Employees
51 - 100 People
