truck gps tracker with RFID gps tracker
Description of A08 gps tracker fuel sensor for truck, car,bus
gps tracker vehicle gps tracker with fuel monitoring RFID reader camera A08 is a mini gps tracker and car alarm system for car, truck and bus. This vehicle alarm systems is small in size, low power consumption, low working current and stable in quality. It supports sending and receiving dispatching information, RFID reader, collecting photos and so on. It is small in size, easy for wire connection.
Technical Parameters
| Item | Specification |
| GSM/GPS module performance | Dual-Band 900Mhz,1800Mhz(850/1900MHz optional) |
| 2 watts EGSM(GSM900 class 4) | |
| 1 watts GSM1800(DCS1800 class 1) | |
| GPRS class 10 | |
| GPS Chipset | Latest U-blox 5M high sensitivity chipset |
| GPS Sensitivity | -160dB |
| Channels | 20/50 channel all-in-view tracking |
| Dimension | 76x66x43mm |
| Weight | 150g |
| Working Voltage | DC 9V~36V |
| Normal power consumption | 80mA (Power Saving Mode<20mA) |
| Working Temperature | -20°C~+60°C |
| Working Humidity | 5%~95% RH |
| Antenna | 1. GPS 2. GSM |
| Interface | 1. 4 Digital Inputs (3 Positive Triggers & 2 Negative Triggers). |
| 2. 1 relay output 250mA 12VDC. | |
| 3. 1 RS232 interface. | |
| Application | 1. Taxi dispatch management. |
| 2. Long distance passage vehicle GPS monitoring. | |
| 3. Bus GPS scheduling management system. | |
| 4. Logistics vehicle GPS monitoring and management system. | |
| 5. Rental vehicle GPS monitoring system. | |
| 6. Extended LED screen for advertising purpose. | |
| 7. Extended LCD screen for dispatching. |
Detailed product information:
1. Locating and Tracking.Information, such as speed, location, moving direction and elevation above sea-level of vehicle, can be tracked by monitoring center anytime.
2. Over-speed Alarm.If the speed of vehicle is over the preset speed, GPS terminal will warn the driver and send over-speed alarm to monitoring centre.
3. Emergency Alarm.If the vehicle is hijacked and backfired, the driver can positively give an alarm to monitoring centre
4. Cut-off of Oil and Electricity.Safely cut-off oil and electrical supply of vehicle in long-range.
5. Alarm of Crossing Border.AS the vehicle runs into or out of the specific area, the monitoring center will accept alarm at once.
6. Playback of Track.Make query of historical tracks of vehicle.
7. Communication Monitoring
8. Message Scheduling
9. Oil Measurement
Characteristics of automobile GPS terminal (advantages):
l Small size: Difficult to find and easy to install,
l Low power consumption: Nearly have no infection to the vehicle battery.
l High integrity: Adopt ARM chip with superior processing
l Excellent Stability: Industrial grade of chip, professional anti-interference process, multilevel battery protection and reliable equipment operation
Characteristics of monitoring center:
l Excellent interface and convenient operation,
l Efficient dispatching system and support of more online vehicle,
l Two version of software(C/S and B/S version), especially B/S version of software is very convenient for customer to examine vehicle and check historical track.
l Software interface of monitoring and control centre can be customized according to customers requirement and habit of usage.
