13.56MHZ USB Interface ISO14443 A/B Smart Card Reader
With optional RS232 interface and no-driving USB
Four card slot support
USB integrated function and reader encryption makes it outstanding
Specifications
Name |
|
Weight |
350g |
Temperature range |
-20~60ºC |
Life span of card contacts |
20,0000 times |
Support card dimensions |
Mostly support two ISO7816 IC card,with two SAM card slot for GSM11.11 (optional) |
Mobile storage capacity |
Optional 16M,32M,64M(can be customized) |
Encryption function |
Optional |
Supply current |
0-70mA |
Communication types with PC |
RS232,Low Speed USB(USB 1.1), No-driving tech |
Communication protocols |
Supports T=0,T=1 CPU card,all types of common storage card,logistics encryption card,Communication rate of up to115,200 bps |
Certifications |
ISO 7816-3,PC/SC,GSM11.11,FCC, CE |
Communication rate |
T=0:9600-38400bps,T=1:9600-115200bps |
Peripheral color |
As picture,can be customized |
Connect cable |
1.5M USB connection line |
Display |
2 LED indicator light,indicate power or communication status |
Operating system |
Windows 98,Me,2K,XP,2003,Unix ,Linux |
Dimensions |
140mm*83mm*60mm |
Others |
Provide function library of universal interfaces,and support various of operating systems& language development platform; Support online upgrade function; Provide development and customization of middle-ware ,such as CSP, PKCS#11; Provide security software’s applications and customization ,Windows Login and VPN... |
Carton Box
Netural Packaging
Shiping way depends on the customer,you can choose UPS,DHL,Fedex...
Support free sample with freight is collected.
More efficient payment and information security
Why choose Decard?
<1> Established in 1999,decard has achieved many successful cases and domestic patents.
<2> The largest researching and development team in smart card reader industry in China.
<3> Top market share nationwide for readers and writers for social security purpose for four years in a row,covering 85% of provinces and cities nationwide.
How about your after-sale service?
We provide all clients with professional advices and your requirements will be replied in 24 hours.
