Home > Security & Protection > Access Control System > Access Control Card Reader > All-in-one Card Reader/NFC Reader

All-in-one Card Reader/NFC Reader

Name: All-in-one Card Reader/NFC Reader
Brand: Decard
SKU: 122660341

All-in-one Card Reader/NFC Reader thumbnail-1

All-in-one Card Reader/NFC Reader photo-1

Negotiable MOQ: 5 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Decard

Model Number:

Z90

Contact Supplier Request Quote Chat Now

Shenzhen Decard Smartcard Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Decard

Model Number Z90

All-in-one Card Reader/NFC Reader Z90

Product Description

32 bit high-speed CPU

High-capacity storage

Supports contact IC card,contact-less IC card and mag-stripe card

Specifications

Central Processor	32bit CPU
Storage	16/32/64M FLASH				Match
	8M/16M/32M PSRAM
Display	Main display	128×64 dot-matrix LCD,multi-language support			Optional
		192×64 dot-matrix LCD,multi-language support
Indicate Light	4,from left to right: blue yellow green red
Press Key	Built-in 17 press key, support keyboard inserted
Voice	voice broadcast support				Match
Buzzer	Support
Peripheral Interface/Communication Mode	Direct outlet		Two USB interface	HID(USB non-director)
	Direct outlet		One DB9 interface One USB interface	RS232 Baud rate115,200 bps
	Direct outlet		One USB socket	available for external password keyboard
	Bluetooth		Support
	NFC		Support
Mag-stripe Card Reader	1/2/3 rail track read,two-way and single side card use				Match
IC Card Reader	2
	Certificated with ISO/IEC 7816
	Support T=0,T=1 CPU card, simultaneously support universal storage card AT24 series,4442,4428...
	T=0:9600-38400bps,T=1:9600-115200bps
	Card contacts can be used to 20,0000times
Contact-less Reader	Support ISO/IEC 14443 Type A/B card, Mifare card,ISO15693 E -tags; Read distance is over 4CM;
SAM Card Slot	4 card slot,certificated with ISO/IEC 7816
Power Supply	Serial interface or USB interface, DC5V±5% with over-voltage protection
Real-time Clock	Built-in real-time clock
Operating Systems	Windows 98,Me,2K,XP,2003,Unix,Linux
Encryption Mode	Encryption mode	Software encryption
	Encryption algorithm	DES,3DES,RSA
Working Environment	Temperature:-20℃~60℃
	Humidity:5~93 percent(non-condensing)
Storage Environment	Temperature:-20℃~70℃
	Humidity:5~95 percent(non-condensing)
Dimensions	1867740.7mm
Weight
Others	Provide function library of universal interface; Support various of operating systems and language development platform; Online upgrading is available; Support customization and development.
Match line	Direct outlet 1.5M two USB interface line cable;				Optional
	Direct outlet 1.5M one DB9 interface,1 USB interface line cable.
	Direct outlet 1.5M one RJ11 socket and two USB interface(or one DB9 interface,1 USB interface)line cable,

Our Services

FAQ

Are you factory or trading company?

Decard is a factory established in 1999, specialize in smart card, RFID and NFC tech related products. We are have professional sale team who can provide you best service.

2.Can I order with my logo printing, size and shape?

Yes,we can do OEM for you.

3.What's your lead time?

In general,3-5 working days of samples new production. ( Depends on craft and request)

The lead time is up to the quantity you order.

More request, please contact us know.
