Outdoor Car Sticker Print and Cut Printer

Name: Outdoor Car Sticker Print and Cut Printer
Brand: yinghe
SKU: 122770787

US$ 3,000 - 8,000 MOQ: 1 Piece

Key Specifications

Condition:

New

Plate Type:

Flatbed Printer

Place of Origin:

Guangdong, China

Guangzhou Yinghe Electronic Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Flatbed Printer

Place of Origin Guangdong, China

Brand Name yinghe

Model Number YHCP400

Usage Paper Printer, Other, Paper Printer, printing and cutting machine

Automatic Grade Automatic

Voltage 220V/110V

Gross Power 1200W

Dimensions(L*W*H) 2.2*0.7*0.8m

Weight 130KGS

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Printer/Cutter All-In-One Machine with DX5 Print Head 1440 dpi for Printing and Cutting

Product Descreption

1. New model Printing&Cutting Plotter

The newest model of Printing and Cutting plotter, used with Ep-son Dx7 printheads.

35’’ printing width, the speed can be 9 sq.m/h.

2. Stable performance

The highest speed for cutting can reach 300 mm/s, and the cutting offset just 0-1.5mm.

The cutting force is 30-800GF, the p ower of media adsorption can be adjusted which avoids printhead scratching with media.

3. Humanized design

Embedded intelligent sectional heating system, auto cleaning system with anti-clogged flash spray&mositurzing function.

Printer information

Model	YH-3000
printhead	Piezo Electric Printhead DX7
Number of Printhead	1 Head
Max Print Width	890mm(35”)
Printing Resolution	4Pass	8m2/hr
	6Pass	6m2/hr
	8Pass	4m2/hr
	16Pass	3 m2/hr
Ink	Type	Eco-solvent ink, UV ink
	Color	Dual 4 colors (C.M.K.Y)
	Capacity	440ml of each ink cartridge
	Ink Supply System	Block brake type of ink supply system
Media	Width	890mm(35”)
	Type	Label, sticker, banner, billboard, vinyl, POP display material etc.
Print Height	1.5-3mm above media adjustable
Cutting speed	10-300mm/s
Cutting offset	0-1.5mm
Cutting force	30-800 GF
Heating System	Embedded intelligent sectional heating system
Media adsorption system	Muti-sectional intelligent air suction system with adjustable strength
Feeding system	Equipped
Auto Printhead Cleaning System	Auto cleaning system with anti-clogged flash & moisturizing function
Clamp	Equipped
Auto take up system	Selectable
Print Interface	HI-USB2.0
RIP software	FlexiSIGN-PRO, SAI
Input Power	AC220V,50Hz/60Hz
Machine Dimension	2190×600×410mm(L×W×H)
Packing Dimension	2320×850×690mm(L×W×H)
