Help CenterTD-M558 Mobile Base Station Transceiver in 400-470Mhz
Related Products
-
Wholesale TD-M558 Mobile Radio Wireless EarpieceUS$ 100 - 118MOQ: 1 Piece -
TID-V32 Tactical Walkie Talkie for SaleUS$ 20 - 40MOQ: 1 Piece
-
Professional TD-V70 Waterproof An-ti Shock Walke TalkieUS$ 20 - 50MOQ: 1 Piece
-
TD-M558 Tour Guide System for SaleUS$ 70 - 125MOQ: 1 Piece
-
TD-V38 Handsfree Walkie Talkie in Special OfferUS$ 25 - 35MOQ: 1 Piece
Specifications
TD-M558 mobile base station transceiver in 400-470Mhz1 DTMF/2 ton/5 tone
2.Microphone lock
3. Mic programmable menu
Company Information:
We are manufacturer of two way radio with 13 years experience. We are concerned with the design, development and production of telecommunication equipment. We have branches in Fujian, Guangzhou and Dubai, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. Our customers have cover more than 100 countries in the world.
Our serives:
Trail order is acceptable, all the products are best quality with 18 months warranty.
We promise small quantity can be ship out once receive payment, big quantity can be shipping out within 1 week after receive payment.
- Menu setting
- Work by repeater station
- Auto repeater offset frequency
- Remote Kill/stun/activate/revive
- Wide/Narrow band setting
- Channel Name editing
- CTCSS/DCS Setting& Scanning
- High/Mid/Low Power selectable
- Voice compander
- Repeater offset shift
- DTMF/2 ton/5 tone
- Talk around
- Voice prompt
- Auto Power off
- Scrambler
- Emergency Alarm
- COMP function
- Scan function
- 1750Hz tone
- ANI ID
- Microphone lock/ Mic programmable menu
- Call keypad
- 200 channels
| Frequency range (TX) | 136-174MHz |
| 245-260MHz | |
| 350-370MHz | |
| 400-490MHz | |
| 470-520Mhz | |
| Frequency range (RX) | 136-174MHz |
| 245-260MHz | |
| 350-370MHz | |
| 400-490MHz | |
| 470-520Mhz | |
| Modulation mode | F3E(FM) |
| Antenna impedance | 50Ω |
| Rated voltage | 13.8V DC ±15% |
| Current | Transmitting <12A |
| Receiving <1.0A (Output 2W) | |
| Frequency stability | ≤±2.5PPm |
| Transmitting | |
| Output power | VHF: 60W(H) 25W(Mid) 10W(Low) |
| UHF: 40W(H) 25WMid) 10W(Low) | |
| Reactance modulation | Reactance |
| Modulation limit | 25KHz±5KH, 12.5KHz±2.5KHz |
| Audio distortion | <5% |
| Adjacent channel power | 25KHz≥65dB, 12.5KHz≥60dB |
| Stray radio frequency measure | <-60dB |
| Modulation character | 3dB~-3dB (Modulation frequency: 300Hz~3KHz) |
| Receiving | |
| Circuitry | Adopt quadratic frequency conversion superheterodyne mode |
| Mid-frequency (1st/2nd) | 49MHz/450Khz |
| Sensitivity | 25KHz<0.2μV, 12.5KHz<0.25μV |
| Selectivity | minus 6dB 25KHz<12KHz, 12.5KHz<10KHz |
| minus 60dB 25KHz<30KHz, 12.5KHz<24KHz | |
| Same channel restrain | >-8dB |
| Adjacent channel selective | 25KHz≥65dB, 12.5KHz≥60dB |
| Stray response anti-interference | 25KHz≥65dB, 12.5KHz≥60dB |
| Intermodulation anti-interference | 25KHz≥60dB, 12.5KHz≥55dB |
| Blocking | ≥90dB |
| Audio response | 1dB~-3dB (Modulation frequency: 300Hz~3KHz) |
| Audio distortion | <5% (>2W)(Microphone internal resistance is 8Ω) |
1. 100% T/T Advance
2. 100% Western Union Advance
3. 100% Pay pal Advance
Shipping Terms
1. EX-works Guangzhou
2. EX-works Hongkong
3. EX-works Xiamen
4. EX-works Dubai
Shipping Method
The delivery can by air/Sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS…
Lead time:
Most of our product have ready stock, sample order is ready any time, and bulk order depend on how many pcs you want.
Packaging :
Unique packaging with durable ,environmental , beauty design character (plastic bag +color gift box).
