Clarkson KGD Slurry Knife Control Gate Valve

Name: Clarkson KGD Slurry Knife Control Gate Valve
Brand: GL VALVE
SKU: 122914911

US$ 500 - 5,000 MOQ: 1 Set

Key Specifications

Standard or Nonstandard:

Standard

Structure:

Gate

Pressure:

Low Pressure

Zhejiang Guanli Valve Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Standard or Nonstandard Standard

Structure Gate

Pressure Low Pressure

Power Other, Bevel gear

Material Casting

Temperature of Media Low Temperature

Media Other, Slurry,powder,cinder,slag

Port Size DN50-DN600

Place of Origin Zhejiang, China

Model Number GLS KGD

Brand Name GL VALVE

Application Other, Industry

Clarkson KGD Slurry Knife Control Gate Valve

Product Description

Features

Size range
DN50 through DN600
Flanges
Drilled to match ANSI B16.5 class 150#
Materials
Body: Cast ductile iron as standard
Gate: SS316 stainless steel with solid solution as standard.
Sleeves: Natural rubber as standard, EPDM and other materials are also available
Yoke: Carbon steel
Actuators
• Bevel gear
• Other actuators available

General applications:

Body

Knife

Unibody design and rugged heavy duty construction ensures long valve life and greater reliability
Flexible two-piece sleeve system allows valve to cycle in heavy slurries without sticking
Sleeves are easily replaced without disassembling the valve
Replaceable upper seal design is not only packingless, which eliminates the need for periodic adjustment, it is also a self-lubricating system and is rechargeable without valve disassembly (sizes 2” through 16”)
Full port design reduces pressure drop and turbulence
Open bottom allows for the purging of large solids and solids in high concentration
Bi-directional shutoff
Wafer style saves pipeline space
Sleeves are available in a variety of materials to handle abrasion and chemical application
Flushing plate option allows for periodic cleaning of the lower discharge vent and allows flushing as needed
Enclosed bronze bushing with a protected grease chamber means less operating force after long dormant periods
Upper stem protector and optional protective lower stem cover prevent external contamination
