High Quality Six Color Infiniti Challenger Solvent Plotter Printer FY-3206R

High Quality Six Color Infiniti Challenger Solvent Plotter Printer FY-3206R thumbnail-1
High Quality Six Color Infiniti Challenger Solvent Plotter Printer FY-3206R photo-1
US$ 8,000 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Guangzhou Caixu Digital Technology Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name Infiniti
Model Number FY-3206R
Usage Bill Printer, Card Printer, Label Printer, Paper Printer
Automatic Grade Automatic
Voltage 220V
Gross Power 1500W
Dimensions(L*W*H) L4, 590 x W1,050 x H890mm
Weight 591KG
Certification CE Certification
After-sales Service Provided Engineers available to service machinery overseas

Infiniti/Challenger stable printer FY-3206R

1.Low ink sensor, auto or manual ink supply system.

2.Double four color printing, vivid color & high speed .

3.X, Y axis AC servo motor Electric drive pinch roller

4. Individual color cleaning minimizes the waste of the ink..

5. 3 way intelligent heater (pre/print/post) helps bring more vivid output.

6. The entire printing platform and the girder are made of the alloy-aluminum which is more strong ,flat and quiet .

SPECIFICATION:

 Model
FY-3206R
Printhead SII Printek Inc.
Drop on demand Piezo Head(SPT510-35PL)
Number of printhead
6 heads
Print Speed(m/h)
Print Mode
Standard Output(m/h)
D
39m2/hr 360X360dpi 1Pass
S
44m2/hr 240X720dpi 2Pass
Q
27m2/hr 240x1080dpi 3Pass
HQ
16m2/hr 720x720dpi 4Pass
Ink

Type
Solvent ink & ECO solvent ink
Color
6 Color (C,M,Y,K,Lc,Lm)
Capacity
1L or 5L per Main Tank of Each Color
Ink Supply System
Low Ink sensor ,Auto or Manual Ink Supply System
Width
3300mm(129,92inch)
Maximum Print Width
3200mm(125,98inch)
Type

Frontlit, Backlit, Vinyl, Polyester, Window Film, Mesh, Leather, Backlit Film, Blue Back Paper
Auto Media Feeding System
Equipped (Max Media Weight 120kg)
Thickness
4mm(Max.)
Heating System
3 way intelligent heater
Auto Media Feeding & Take-up System
Equipped
Auto Cleaning System
Positive Pressure Cleaning, Anti-Clogging Flash Function&Capping System
Print Interface
USB2.0
Printhead height
Above Media Adjustable
Power Specification
Printer :AC 220V, 50Hz 3.5A 770W/Heater: AC 220V,50HZ 9A 1980W
Operational Environment
Temperature:20°C-28°C Humidity:40%-70%
Compatible RIP Software
Photoprint, UltraPrint,Topaz,Wasatch,Caldera,Maitop
Machine Dimension
L4,500 x W905 x H1,260mm; Net Weight: 348Kg
Package Dimension
L4,590 x W1050 x H890mm; Net Weight: 591Kg




Pictures to reference :

Front side of printer  FY3206R , strong body.

Back side of the printer.

Temperature controller , all kinds of button to keep runing smoothly and safely .

Inside of the left box . AC servo motor keep the printing stable.

Pumps and filter

Individual color purging equip , minmizes the waste of ink

Print head position

Good quality print head board , ensure print good quality picture.

Strong upper beam and top quality motor to run the carriage  quicker and quiet.

Wide table , 3 ways heating system.

We always keep stcoking all kinds model of printer



other product:



 We supply all kinds of spare parts , including all kinds of brand main board , print head boards , ink tube ,print head ,ink,etc . Any intersting , please feel free to contact us .



-



How to order?

Step 1. Contact with me about the details and product you need.

Step 2. Confirm the order to us, provide the following information, then we will send you Proforma Invoice (PI) for your reference.

Order Details ( Items and Quantity), Company Name, Contact Person, Address, Telephone, Sea port of destination

Step 3. Send payment T/T in advance and notify us (send Bank Slip to us)

Step 4. We will deliver the goods within 5 working days after receipt of your payment, and keep you informed about the order status.

Balance payment should be paid upon copy of B/L.On receipt of balance payment, we will send you original shipping documents by DHL and let you know the tracking number.

Step 5. Confirm to us upon receipt of order.
