Specifications
1.SCG100 Chewing gum wrapper2.PLC controlling system
3.Speed:110-130 sticks/min
4.4-10 grains/stick
SCG110 Chewing gum stick packing machine
Main Technical Parameter:
Packaging speed |
110~130sticks/min |
|
Total power |
2KW AC380V |
|
Weight |
2500KG |
|
Control system |
PLC,Touch screen,frequency converter,Photocell, Mechatronics. |
|
Overall dimensions |
2400*1300*2200mm(L*W*H) |
|
Working condition |
Temperature:18~21°C;humidity:45~55% |
|
Packing materials specification and requirements |
Out paper reel |
Max dia.:φ350 |
Width:54-174mm | ||
Installation Core dia. |
76mm |
|
Characteristics and performance:
This machine includes the feeding machine and packing machine. The feeding machine will align the chewing gum grain from the hopper into a line in the feeding tunnel by electromagnet vibrator and then send these
chewing gum grain into the packing machine. The packing machine takes these chewing gum and packs
4-10 chewing gum grain into a stick with one paper. The biggest advantage of this machine is that the
dual-tunnel for feeding and package machine is adopted. Thus the packing speed is improved greatly.
The performance of this machine is steady and reliable under running.
This machine adopts excellent electric appliance, PLC control system, a frequency converter for infinite speed adjustment, photocell system and automatic compensating function with servo motor for accurate cutting of the outer paper, operator-machine interface for setting, amending and saving all parameters during running.
The protection covers are used in the mechanical driving parts. This machine is designed for massive
production of chewing gum sticks in the food industry.
