Multi Needle High Speed 800RPM Computerized Multi-needle Shuttle Quilting Machine
>Extreme precision with 360 intricated patterns including bartack and jump patterns with automatic
top thread cut.
>High performance aircraft aluminium-alloy-bushless needle-drive parallelogram system assuring
a smooth and frictionless high speed round the clock working without any maintenance.
>Unique design of upper creel makes it easy to exchange upper thread.
>Unique adjustable(0~50~80mm) active roll feeding system can adjust ideally materials of different thickness and allow perfect sewing without skipped stitches on very thick materials.
>Independent positive presser foot system,with wide possibilities of adjusting stroke and
passage clearance, Capable of compressing thin or very thick filling materials(up to 80mm)
>Top fabric tray feeding device with adjustable brake, gives a constant and accurate top
fabric tension control to any kind of fabric, independent of the rolls diameter.
>The photoelectric thread break detector has the features of high sensitivity.
Note :The PLC control System are from TAIWAN and two Servo Motor China Taiwan
Xinjie Best Brand.
Technical parameters:
1.Model No:TD-96C
2.Size length X width X Height:5100x1500x2000mm
3.Quilting width:2450mm=96inch
4.Rotation speed:500-800
800-1000RPM
5.Production speed:20-190m/h
6.Needle size:140/22
7.Needle arrange:76.2, 152.4
8.Row sapce 3”x2” or 3x3”
9.Quiliting thickness 2-8cm
10.Voltage 380v/220v 50HZ/60HZ
11.Needle rows :2
12.X and Y-axis servo system with Panasonic servo motors
(1)Inverter (2)Servo Motor
(3)LCD Computer touch screen system.brilliant display and easy to operate
