One Way Clutch Bearing CSK35-2RS CSK10 Sprag Clutch One Way Bearings

One Way Clutch Bearing CSK35-2RS CSK10 Sprag Clutch One Way Bearings thumbnail-1
One Way Clutch Bearing CSK35-2RS CSK10 Sprag Clutch One Way Bearings photo-1
US$ 0.2 - 1 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
SEMRI or TFN(our brand) or OEM
Bore Size:
35, 35.005
Outside Diameter:
72, 72.005
Contact Supplier Request Quote Chat Now
Tianjin Semri Bearing Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang port China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name SEMRI or TFN(our brand) or OEM
Bore Size 35, 35.005
Outside Diameter 72, 72.005
Model Number csk35 2RS
Precision Rating P0, P2,P3, P4,P5,P6
Seals Type Open / Sealed
Place of Origin Shandong, China

one way clutch bearing CSK35-2RS CSK10 sprag clutch one way bearingsTIANJIN SEMRI BEARING TECHNOLOGY CO.,LTD

Product Description



one way clutch bearing CSK35-2RS CSK10 sprag clutch one way bearings

Type CSK are sprag type freewheels integrated into 62.. series ball bearings. It is bearing supported, shipped grease lubricated and protected against dust larger than 3mm diameter.

Torque transmission is ensured by a press fit assembly into a rigid outer housing with N6 tolerance, and onto a shaft with n6 tolerance

Operating temperature range: minus 40 deg F (minus 40 deg C) to plus 212 deg F (plus 100 deg C), Peaks up to 248 deg F are acceptable for short periods of time



the size of CSK35-2rs
d: 35mm
D: 72mm
W: 17mm
Torque capacity: 240Nm
Max overrunning speed: 3,600rpm
Bearing load dynamic: 12.6kN
Bearing load static: 7.28kN
Weight: 0.400





one way clutch bearing have lots of characteristic,such as long Service life,big Torque and low nosy.abroadly used in several areas,such as mining /hydraulic / textile / printing / washing machines, conveyor systems and so on.



Below is my company product model and parameter:



One way clutch bearing CSK35-2RS and other model :



one way (direction) bearing, one way direction bearing, one way direction bearings, One-Way Roller Clutch Bearing, One-way Needle Clutch Bearing, clutch, one-way bearings, single-direction bearings, special-bearings, CSK12, CSK15, CSK17, CSK20, CSK25, CSK30, CSK30, CSK35, CSK40, CSK-12, CSK-15, CSK-17, CSK-20, CSK-25, CSK-30, CSK-30, CSK-35, CSK-40, CSK 12, CSK 15, CSK 17, CSK 20, CSK 25, CSK 30, CSK 30, CSK 35, CSK 40

CSK Series (One-Way Bearing) The CSK model freewheel is a sprag type clutch integrated into a 6200 series ball bearing (except sizes 8 and 40). It provides you with a one way clutch, and eliminates the need for a ball bearing. It gives a high degree of freewheeling accuracy while utilizing a minimum of space.
The CSK model freewheels can be used in backstop, overrunning or indexing applications.
For SPINNING REELS (fishing baitrunner Reels/Fishing Reels), The tension of the free spool can be controlled with an easy to reach rear adjustment. Nine stainless steel , sealed bearing and a one-way clutch bearing make these reels smooth.
CSK series one way (direction) bearing consists of a standard ball bearing, in-built special snap block and cage, widely used in washing machine, hydraulic machinery, printing machines, textile machinery and so on.



TYPE

keyway

Dimensions(mm)

Nominal torgue

weight

GERMANY

JAPAN AND OTHER

d

D

B

N.m

KG

CSK8

BB8   KK8 OW8

P

PP

8

22

9

2.5

0.015

CSK10

BB10   KK10 OW10

P

PP

10

30

9

5

0.032

CSK12

BB12   KK12 OW12

P

PP

12

32

10

10

0.04

CSK15

BB15   KK15 OW15

P

PP

15

35

11

30

0.05

CSK17

BB17   KK17 OW17

P

PP

17

40

12

48

0.07

CSK20

BB20   KK20 OW20

P

PP

20

47

14

60

0.11

CSK25

BB25   KK25 OW25

P

PP

25

52

15

80

0.14

CSK30

BB30   KK30 OW30

P

PP

30

62

16

100

0.21

CSK35

BB35   KK35 OW35

P

PP

35

72

17

123

0.30

CSK40

BB40   KK40 OW40

P

PP

40

18

22

260

0.50









Product show



one way clutch bearing CSK35-2RS CSK10 sprag clutch one way bearings



Packaging & Shipping

Package

1.Industrial packaging: Plastic tube (10pcs in one tube)+ carton + plywood pallets; plastic bag + kraft paper + carton + plywood pallets;

2.Commercial packing: 1pc/plastic bag+ single color box+ carton + plywood pallets;

3.According to customer’s requirement

one way clutch bearing CSK35-2RS CSK10 sprag clutch one way bearingsone way clutch bearing CSK35-2RS CSK10 sprag clutch one way bearings

Shipping

Express,air shipment, and sea shipment are available,according to customers' requirement

Our Services

1.Any inquiries will be replyed within 24 hours.
2.Professional manufactory for 6 years.
3.OEM service:

1).we can customize lots of different types of bearings with different brand,different material

2).Any your idea on bearing we can help you to design and put it into production.

4.Famous brand bearings also available

5.Quality First, Credibility Supremacy, Price Reasonable, Excellent Service

6.After-sale service:

1).All products will have been strictly  Quality Checked in house before packing.

2).All products will be well packed before shipping.

3).our company provices technical assiatance as the customers requirement and needs.



Company Information

Tianjin SEMRI Bearing Technology Co.,Ltd is a leading manufacturer of ball, roller bearings, pillow block bearings and other bearings  in China. We specialize in research and development of various kinds of high precision, non-noise, long-life bearings, high quality chains, belts, auto parts and other machinery & transmission products.



"Quality First, Customers First and Credit First" is our management tenet. We warmly welcome you to contact or visit us. Let's create a bright future together!

FAQ

Why choose SEMRI?



1. We are professional

Modern standard workshop,

Advanced production facility,

2. We are experienced



We specialized in manufacturing construction machine parts for over 10years



Our  products have been sold overseas and won the trust and support of the board clients both at home and aboard.

3.We can offer a various kind of bearing with high quality:Z1V1,Z2V2,Z3V3 and best price

4.Our main products: Deep groove ball bearing ,Cylindrical roller bearing, Pillow block bearing, Tapered roller bearing, Angular contact ball bearing, Thrust roller bearing , ect

5.Free Samples can be sent for your evaluation





What about after-service?

We stress on service of our products, and have a perfect after-sale service system. We set up corresponding mchanism, in order to release and warm the consummers rapidly and effectively when the products go wrong. We will trace the cause if products have problem. after confirming the detail, we would find out a solution for it.



Where’s your company?
   Our own factory is located in shandong provience.Our office is in Tianjin city,

    which is a automobile parts city.

Can I visit you?
    Yes, Welcome to visit us. It is very convenient to come our factory,

      All our clients, are warmly welcome to visit us!

How is the quality of your products?
    The same quality, we have lower price.The same price,we have better quality.

Can I get free samples?

    we will charge a little sample fee for our regular designs or customized ones,

    These charges will be refunded to you when your mass production order is confirmed.

 Can you make the products as our requirement?

    We have more than 10years’ OEM experience. We supply products fo more than 300 automobile parts factories.

 What is the minimum order quantity?

   Our MOQ is 1 PCS.
