Help CenterFU Sintered Bronze Bushing Flanged Bronze Bearing
Related Products
Specifications
24 hours : Reply inquiry and questions3 days : Finish the drawings
7 days : Open the new mold
30 days: Delivery the goods
FU sintered bronze bushing Flanged Bronze bearing
FU sintered bronze bushing powder is mold pressed under high pressure and then sintered under high temperature, and oil is soaked into the homogeneously spreaded tiny pores of the metal under vacuum. Fu bearing can withstand dry condition in medium speed and low load for sometime. Moreover it is cheap and stable in dimension. This is widely used in domestic electric and electronic machines, electric tools, textile machines, chemical engineering machines, automobiles and official business machines.
Specifications :
Load capacity:35 N/mm²
Temperature Limt:-80~+160 °C
Speed limit:2.5 m/s
PV Limit :2.45 N/mm² .m/s
| Material type | Cu % | Sn % | Zn % | Pb % | Fe % | C % | The others % |
| Cu663 | the rest | 5~7 | 5~7 | 2~4 | < 0.5 | 0.5~2.0 | < 1.5 |
| Material type | Cu % | Sn % | Zn % | Pb % | Fe % | C % | The others % |
| Cu660 | the rest | 5~7 | 5~7 | < 0.1 | < 0.5 | 0.5~2.0 | < 1.5 |
| Material type | Cu % | Sn % | Zn % | Pb % | Fe % | C % | The others % |
| Cu9010 | the rest | 8~11 | < 0.5 | 0.5~2.0 | < 1 | ||
| Material type | Cu % | Sn % | Zn % | Pb % | Fe % | ||
| Cu55Fe | the rest | 2~2.8 | 2~2.8 | 0.8~1.6 | 48~50 |
Our copmpany has supplied all kinds of bushings for over 10 years.
Should any of these items be of interest to you, please let us know.
We will be happy to give you a quotation upon receipt of your detailed requirements.
