RY-IP012 HD 720P Outdoor IP Camera 3.6mm Network CCTV Night Vision Camera Quality Choice

Name: RY-IP012 HD 720P Outdoor IP Camera 3.6mm Network CCTV Night Vision Camera Quality Choice
Brand: RUIYE
SKU: 123408269

US$ 22 - 38 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

RUIYE

Model Number:

RY-IP012

Shenzhen Rui Ye Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name RUIYE

Model Number RY-IP012

Type Digital Camera

Style Bullet Camera

Sensor CMOS

Technology NetWork

Special Features Waterproof / Weatherproof

Features:

* Max resolution can reach 1.0M(1280×720), HD 720P output, real-time image

* 0.6Lux @(F1.2,AGC ON),0 Lux with IR

* Support IR-CUT filter switch to achieve day and night monitoring

* H.264 main profile compression, achieve low bit-rate, high definition image quality

* Support dual stream

* Support mobile monitor(iPhone, Windows Mobile, BlackBerry, Symbian, Android)

* Support Auto-iris and electronic shutter, adjust for different surveillance environment

* Provide web, V2277, center manage software (MYEYE), and SDK for development

* Support connection with NVR

* System Compatibility: ONVIF

* Accord with IP66 waterproof design

Application:

Apply for Road, Warehouse, Underground car parks, Bar, Pipeline and somewhere with poor sunshine.

Specification

Parameter	1.0MP IR Led Network Camera
Camera
Image Sensor	1/4" OV CMOS Sensor
Min illumination	Color: 0.6Lux @(F1.2,AGC ON),0 LUX with IR
	B/W:0.08 Lux @ (F1.2,AGC ON),0 LUX with IR
Electronic shutter	1/50(1/60)s- 1/100,000 s
Day & Night	IR-CUT&auto
Lens	3.6mm
Lens Mount	CS
Compression
Video compression	H.264 HighProfile,JPEG capture
Video Bite Rate	32 Kbps~6Mbps
Audio compression	G.711a
Max Resolution	1280*720
Frame Rate	50Hz:25fps (1280*720) PAL
	60Hz:30fps (1280*720) PAL
Image settings	Saturation, Brightness, Contrast adjustable through Client software or webserver
Network Function
Storage	Support network storage
Intelligent Alarm	Motion detect, video loss ,network disconnection, IP address conflict, storage full, storage error
Protocol	TCP/IP,HTTP,DHCP,DNS,DDNS, PPPoE, SMTP,NTP
	(HTTPS,SIP ,802.1x,IPv6 optional)
Basic	Anti-flicker, dual stream, heartbeat, password protection, ONVIF
Interface
Communication Interface	1 RJ45 10M/100M self-adaptive Ethernet interface
General
Operating condition	-10℃~60℃,humidity 90% less (non-condensing)
Power supply	DC12V±10%
Power consumption	7.5W MAX;
Protection Range	IP66
IR distance	“LED IR”:10-30 M;
