19mm Key Switch Lock

19mm Key Switch Lock photo-1
Negotiable MOQ: 2000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
JINTAY
Model Number:
S202ZB
Payment & Shipping
Payment Methods:
Port of Shipment:
TAIWAN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin China
Brand Name JINTAY
Model Number S202ZB

Specifications

1. large full size switch lock.
2. Zinc alloy die casting housing and cylinder.
3. switch function on-off-on
4. 10000 codes

No.: S202ZB
Product Name: Key Switch Lock
DESCRIPTION:
  • Zinc alloy die cast housing and cylinder
  • Bright chrome plated standard.
  • 7 pin tumbler mechanism.
  • Steel made tubular keys, nickel plated.
  • Key may be withdrawn in one or both or three positions.
  • Silver plated contacts and terminals.
  • S202ZB 3 position (on-off-on) 4 terminals.
  • S202ZC 3 position (off-on-on) 4 terminals.
  • S202ZD 2 position (on-on) 4 terminals.
  • S202ZDA 2 position (on-on) 4 terminals, spring loaded for
    momentary contact.
  • Hex nut mounted.
  • All keyed alike or one combination per 100pcs standard.
  • 10000 combinations available.
KEY-PULL FIGURES :

-Off Position
-Indicates Key-Pull
-Indicates No Key-Pull



Fig. No. Lock Number Pole Positions Terminals Key Pulls Turn Type
1 S202ZB 1 3 4 3 45°-0°-45° On Off On   SPDT
2 S202ZC 1 3 4 3 45°-0°-90° Off On   On SPDT
3 S202ZD 1 2 4 2 90 °   On   On SPDT
4 S202ZE 2 2 4 2 45 °   Off On   SPST
