Help CenterFire Butterfly Valve
Related Products
-
A395 Ductile Iron Double Flanged Butterfly ValveUS$ 1 - 1MOQ: 1 Piece -
Lug Type Butterfly ValveUS$ 1 - 1MOQ: 1 Piece
-
Water Wafer Butterfly ValveUS$ 3 - 10,000MOQ: 1 Piece
-
Universal Standard Handle Wafer Butterfly Valve Without PinUS$ 1 - 1MOQ: 1 Piece
-
Stainless Steel Lug Type Butterfly Valve ManufacturerUS$ 3 - 10,000MOQ: 1 Piece
We Tianjin Ansheng Valve Co., Ltd specialize in valve manufacturing for 15 years, with best quality, best service and competitive price, and we are Alibaba Gold Supplier.
More services we can provide:
1. Professional free design
2. OEM support
3. Low MOQ
4.Fast delivery
5. Free sample
6. Door to door service
Features:
1.Small in size and light in weight. Easy installation and maintenance. It can be mounted wherever needed.
2.Simple and compact construction, quick 90 degree on-off operation.
3.Flow curve tending to straight line. Excellent regulation performance.
4.Long service life. Standing the test of thousands opening/closing operation.
5.Wide selection of materials, applicable for various media.
Standard:
| Design standard | Face to Face | End Flange | Test&Inspection |
|
MSS SP-67 API60 EN593
|
API609 ISO5752 series20 BS5155 |
DIN PN10/16/25 ANSI B 16.1 BS4504 ISO PN10/16 JIS B 2212/2213 BS 10table D BS 10table E |
API 598 |
Technical Data:
| Lug type worm actuated wafer butterfly valve | |
| Product Model | LTD71X-10/16 |
| Nominal Diameter | DN40~200mm |
| Nominal Pressure | PN1.0~1.6MPa |
| Suitable Medium | Water,gas,oil,etc |
| Suitable Temperature | -23°c~121°c |
Material of Main Parts:
| Body | CI/DI/WCB/SS |
| Disc | DI/ALB/WCB/MONEL/CF8/CF8M |
| Stem | SS416/SS304/SS316/WCB |
| Seat | EPDM/BUNA/NBR/NR/PTFE/HYPALON/VITON/NEOPRENE |
Packing and Transport:
1.100% factory price, because we are direct producer of butterfly valves, check/non-return valves, gate valves and so on.
2.Market, technical support and after-sale service within 24 hours.
3. You can order your own configuration.
A: Manual B: pneumatic C: electric D: bare shaft E: disc with pin F: disc without pin G: double half shaft H: one piece body I: two pieces body J: logo
4.All valves are tested twice before and after hammer pin to ensure its perfect sealing property.
5.Valves' back seats are phenolic resin under DN350 while above DN400 are aluminium back seat to prolong its working life.
6.Concentric valves can ensure zero leakge.
