Specifications
1.MCCB with 225 frame level2.CE&CB&SEMKO certificates
3.plenty OEM experiences
4.well for international markets
Application:
AUM1 MCCB features good structure,small volume and reliable performance.It can be used on the 50/60Hz,rated voltage to 440V supply .It can protect the cable and equipments from overload or short circuit.It can also be used as switch for infrequently making or breaking of the circuit.
Technical data:
Number of pole:3P,4P
Rated voltage(Ue):400V
Rated current(In):100,125,160,180,200,225A
Rated isolating voltage(Ui):800V
Rated impulse withstand voltage(Uimp):6000V
Mechanical endurance:7000 cycles
Electric endurance:1000 cycles
Connection:Terminal Screw
Rated limit short-circuit breaking capacity(Icu):50kA
Rated operating short-circuit breaking capacity(Ics):27kA
Standards:IEC60947-2,EN60947-2
Weight:1954g
Catalog No. CTN Size:60x33x19cm
| Model | Description | QTY/Box | QTY/CTN |
| AUM1-225 | 3P 100A 35kA | 1 | 8 |
| AUM1-225 | 3P 125A 35kA | 1 | 8 |
| AUM1-225 | 3P 160A 35kA | 1 | 8 |
| AUM1-225 | 3P 180A 35kA | 1 | 8 |
| AUM1-225 | 3P 200A 35kA | 1 | 8 |
| AUM1-225 | 3P 225A 35kA | 1 | 8 |
| AUM1-225 | 4P 100A 35kA | 1 | 8 |
| AUM1-225 | 4P 125A 35kA | 1 | 8 |
| AUM1-225 | 4P 160A 35kA | 1 | 8 |
| AUM1-225 | 4P 180A 35kA | 1 | 8 |
| AUM1-225 | 4P 200A 35kA | 1 | 8 |
| AUM1-225 | 4P 225A 35kA | 1 | 8 |
About us:
Aoelec Electrical was established in 2003,with 50 office guys and 240 workers now.Our products are present in more than 30 different countries from Middle Ease to South American,from Europen to Australia,from Southeast Asia to North Africa.And our product have KEMA,TUV,SEMKO,CB and CE certificates.
