Optical Fiber Curing Oven,OFO-4800
Description:
Vertical fiber curing oven OFO-4800 is a kind of high efficiency equipment, which is designed by Shenzhen Neofibo Technology Co., Ltd. With full practices of many end users, it meets all the requirements of fiber curing. Based on its high performance and stability, this kind of curing oven has more reputation from users and it is one of the best salable equipment in optical fiber patch cord factories .
Technical Parameters:
l Input Power: 220V AC 50/60Hz, 600W
l Upper Limit for Heating Temperature:200 Celsius degrees
l Recommend temperature: 80~120 Celsius degree
l Recommended Heating time: 30~45 minutes
l Capacity: 1~48 positions for ferrules.
Necessary Accessory:
Ferrule Installation Fixture
Operation Process for Curing Oven:
1. Push the red switch to turn on the power(See Piture 1).
2. Setup Target Temperature and Heating Time, and the oven starts warm-up. Please see Temperature Setting and Time Setting to leanrn more. (See OFO-4800 Temperature Control Setting Guide)
Temperature Setting: PV is measured value, and SV is the setting value (100 celsius dgree or higher, it could be modified after power on).
Time Setting: It is easier than Temperature Setting
