Specifications
1.diesel generator set engine2.model cummins 6LTAA8.9-G2
3.made in china
1.diesel generator set engine
2.model cummins 6LTAA8.9-G2
3.made in china
KLex Generator set model |
KLS-C220A |
|
Rated power |
Spare power |
|
Generator set power(KW) |
200 |
220 |
Generator Set Power (KVA) |
250 |
275 |
Engine Power(KW) |
220 |
243 |
Engine model |
6LTAA8.9-G2 |
|
Engine Manufacturer |
DCEC Cummins |
|
Engine structure |
6 cylinders in line, 4 strokes Exhaust turbocharger, air to air mid-cooling |
|
Engine cooling way |
Meet the environmental temperature 60 water tank radiator, the belt drive the cooling fan, with Fan safety shield |
|
Governing system |
High precision electronic speed control system |
|
Start way |
24V DC motor starter With silicon rectifier charging generators |
|
Engine filter system |
Dry type air filter, Fuel filter, Oil filter, Coolant clarifier |
|
Fuel system |
High pressure electronic speed fuel system |
|
Engine general displacement(L) |
8.9 |
|
Compression ratio |
16.5:1 |
|
Bore x Stroke |
102x120mm |
|
100% Load fuel consumption (L/h) |
42 |
45 |
Intake flow (L/min) |
778 |
|
Exhaust flow (L/min) |
2209 |
|
Exhaust Temperature (°C) |
556 |
|
The maximum allowed exhaust back pressure(KPa) |
10 |
|
Oil capacity(L) |
23.8 |
|
Cooling fluid capacity(L) |
35 |
|
Generator set manufacturer |
Sino-British Joint Venture Wuxi Leopard Generator Set |
|
Short-circuit protection |
air switch |
|
Rated voltage/frequency/power factor |
400V/230V,50Hz,0.8 lag,three phase four wire |
|
Steady frequency variation |
0~5% can be set |
|
No-load voltage adjustment range |
≥ 95%~105% |
|
Steady-state voltage adjustment rate |
better than ± 1% |
|
Insulation class/protection level |
H class/IP22 |
|
Telephone influence coefficient/ Harmonic coefficients |
TIF>50/ THF<2% |
|
Attached with the generator set |
Fuel tank, lead-acid high-energy battery, bending Smoke tube, sylphon bellows, flange, slencer one set, anti-shock pad one set, manual |
|
Generator set overall dimension(mm) |
2480x820x1480 |
|
Generator set(Kg) |
1840 |
|
