Help CenterOpen Braided Expandable Sleeve
US$ 0.1 - 9.9
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
JDD-SCS
Type:
Other, Cable wrap
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Self-wrapping Split Braided SleevingUS$ 0.4 - 3MOQ: 1000 Meters -
DIN5510 Zipper Shielding WrapUS$ 0.068 - 7.6MOQ: 3000 Meters
-
BS6853-Self-closing WrapUS$ 0.056 - 7.3MOQ: 3000 Meters
-
DIN5510-Polyester Self-closing WrapUS$ 0.065 - 8.2MOQ: 3000 Meters
-
Self Closing WrapUS$ 0.666 - 3.4999MOQ: 1000 Meters
Place of Origin
Guangdong, China
Model Number
JDD-SCS
Type
Other, Cable wrap
Material
PE
Specifications
lightweight,cost-effective and tough solution for the protection of a wide range of components.Flexibility,open designDescription:
JDD-SCS self-closing wrap is a non-expandable sleeving woven from monofilament (weft) and multifilament (warp) polyester yarns. It provides a lightweight, cost-effective and tough solution for the protection of a wide range of components. Its inherent flexibility allows it to bend,coil and conform to irregular shapes, while its open design allows it to be installed on completed assemblies.
Application:
Most commonly used on wire harnesses, cable assemblies, flat ribbon cables, tubes and hoses to provide a tough, durable protection in automotive, automatic equipment, railways and panel boards.
| Part No. | Size(d) | Max.bundle Dia | Packing(L) |
| SCS-005 | 5.0 | 6.0 | 100m/spool |
| SCS-008 | 8.0 | 9.0 | 100m/spool |
| SCS-010 | 10.0 | 11.0 | 100m/spool |
| SCS-013 | 13.0 | 14.0 | 50m/spool |
| SCS-016 | 16.0 | 17.0 | 25m/spool |
| SCS-019 | 19.0 | 20.0 | 25m/spool |
| SCS-025 | 25.0 | 26.0 | 25m/spool |
| SCS-029 | 29.0 | 31.0 | 25m/spool |
| SCS-032 | 32.0 | 34.0 | 25m/spool |
| SCS-038 | 38.0 | 40.0 | 25m/spool |
| SCS-050 | 50.0 | 52.0 | 25m/spool |
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2004
Factory Size
5,000-10,000 square meters
Total Employees
101 - 200 People
