LED Interactive Board, Interactive Touch Board, Interactive Smart Board
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Wanin
Model Number:
TL6515E
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LED Interactive Multimedia Board/Large Led Interactive Board /led Touch PanelUS$ 1,500 - 2,000MOQ: 1 Piece -
Mobile Electronic Whiteboard System WM800ANegotiableMOQ: 1 Piece
-
55" Large-screen LED Touch Panel, Interactive Display Board, Infrared LCD Touch PanelNegotiableMOQ: 1 Piece
-
70" Large-screen LED Interactive Board / Touch PanelUS$ 2,500 - 4,000MOQ: 10 Pieces
-
LED Multi Touch Screen Monitor TV, LED Interactive Whiteboard/ Large LED Touch PanelNegotiableMOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Wanin
Model Number
TL6515E
Specifications
LED Interactive board, interactive touch board, interactive smart board,which integrates LED TV and touch screenReal two touch
LED Interactive board/ interactive touch board/ interactive smart board
is a new generation display equipment, which integrates LED TV and touch screen,it is a one stop solution which adds interactivity and energies to any training, learning, work reporting environment to improve the efficiency and effectiveness of communication.
SPECIFICATIONS:
| Model | TL-5515E | TL-6515E | TL-7003 |
| Display | LED | LED | LED |
| Diagonal size | 55" | 65" | 70" |
| Displaying surface | 47.6"(H)×26.8"(V) | 56.2"(H)×31.6"(V) | 70"(H)×34.3"(V) |
| Displaying rate | 16:09 | 16:09 | 16:09 |
| Effective pixels | 1920×1080 | 1920×1080 | 1920×1080 |
| Brightness | ≥500cd/m² | ≥500cd/m² | ≥500cd/m² |
| Viewing angle | >176° | >176° | >176° |
| Contrast | 5000:1 | 5000:1 | 5000:1 |
| Reaction time | 5ms | 5ms | 5ms |
| TV function | Support all kinds of analog and digital TV | Support all kinds of analog and digital TV | Support all kinds of analog and digital TV |
| Touch Device | |||
| Sensor | Infrared | Infrared | Infrared |
| Resolutions | 4096×4096 | 4096×4096 | 4096×4096 |
| Multi-touch | 2 Points | 2 Points | 2 Points |
| Response speed | ≤16ms | ≤16ms | ≤16ms |
| Positioning accuracy | ±2 mm | ±2 mm | ±2 mm |
| Writing tool | Any object with diameter above 5mm | Any object with diameter above 5mm | Any object with diameter above 5mm |
| Working temperature | -5°C ~ +40°C | -5°C ~ +40°C | -5°C ~ +40°C |
| Input Terminals | |||
| HDMI | ×2 | ×2 | ×2 |
| VGA | ×3 | ×3 | ×3 |
| YPbPr | ×1 | ×1 | ×1 |
| S-VIDEO | ×1 | ×1 | ×1 |
| VIDEO | ×2 | ×2 | ×2 |
| AUDIO | ×3 | ×3 | ×3 |
| RF IEC | ×1 | ×1 | ×1 |
| RS232 | ×1 | ×1 | ×1 |
| MIC | ×1 | ×1 | ×1 |
| USB(Multimedia) | ×1 | ×1 | ×1 |
| Output Terminals | |||
| VGA | ×1 | ×1 | ×1 |
| VIDEO | ×1 | ×1 | ×1 |
| SPDIF | ×1 | ×1 | ×1 |
| AUDIO | 2 | 2 | 2 |
| USB (Touch) | USB Slave Touch Out×1 | USB Slave Touch Out×1 | USB Slave Touch Out×1 |
|
Embedded PC (Optional) |
|||
| CPU | Intel G620 2.6GHz/Intel i3 2100 3.1GHz | ||
| Memory | 2G | 2G | 2G |
| Main board IC | Intel H61 | Intel H61 | Intel H61 |
| Hard disk | 320G/500G | 320G/500G | 320G/500G |
| Inputs and outputs | LAN×1,USB≥4 | ||
| Other | |||
| Power consumption | 220W | 250W | 400W |
| Dimensions | 1367×826×123.5(mm) | 1589x959x122.4(mm) | 1711x1033x141.3(mm) |
| Weight | 50KG | 60KG | 110KG |
| Installation | Wall mount,Moving stand(optinal) | ||
WANIN has been the leading vender in China's education electronics market for over a decade, and is now gaining reputation in USA , EU as well as majority of Asian countries. We take great pride in offering quality products to our worldwide customers and we are now looking forward to the opportunity of serving you.
Warm Welcome your kind inquire and visiting
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2001
Factory Size
10,000-30,000 square meters
Total Employees
201 - 300 People
