Water Cooled Marine Diesel Generator With Price
US$ 8,000 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
U-POWER
Model Number:
Deutz 226B
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Price! Weichai Marine Diesel Engine With CCS CertificateUS$ 4,000 - 30,000MOQ: 1 Set -
Low Price! Weichai WD615 Marine Diesel Engine With CCS/BV/ZY/KR/RSUS$ 2,000 - 30,000MOQ: 1 Set
-
Low Price! Weichai Steyr WD618 Marine Diesel Engine Made in Weifang CityUS$ 2,000 - 30,000MOQ: 1 Set
-
Low Price! Weichai WP12C With Marine Diesel EngineUS$ 1,200 - 35,000MOQ: 1 Set
-
Low Price ! 250-400KW Marine Generator Made in Weifang CityUS$ 20,000 - 25,000MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
U-POWER
Model Number
Deutz 226B
Output Type
AC Three Phase
Speed
1500rpm
Frequency
50HZ
Rated Power
100kw
Rated Voltage
400/230v Optional
Rated Current
180A
Specifications
1)30-120kw marine diesel genarator2)stable performance,energy saving
3)deutz engine,Stanford generator
4)warranty for 1 year
Weichai Deutz 226B Series Marine Generating Sets
are powered by 226B series diesel engines which are produced by the joint wenture company of Weichai and Deutz Company, Germany, and fitted up with renowned generators. The power output range is 24-120kW, CSS and ZY, BV certification can be supplied.
GB/T13032-1991 Standard is applied for the manufacture and inspection of the generating sets.
Main components of the generating sets:
Generator: Marathon, Stanford and Lanzhou generator with F or H insulation grade.It is also available for load to be transferred between gen-sets at normal running.
Parallel connection: Two and more normal marine generating sets can transfer loading without stopping, and can realize parallel.
| Genet Model | Continuous output(kW) | Rated Voltagey(V) | Rated currency(A) | Rated loading fuel consump(kg/h) | 226B Series Diesel Engine | |||||
| Engine model | Max output(kW) | Rated speed(r/min) | Governing method | Starting method | Cooling method | |||||
| CCFJ24J-WJ | 24 | 400 | 43.5 | 4.8 | D226B—3CD | 33 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ30J-WJ | 30 | 400 | 54 | 5.9 | TD226B—3CD | 44 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ40J-WJ | 40 | 400 | 72 | 7.9 | TD226B—4CD | 66 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ50J-WJ | 50 | 400 | 90 | 9.9 | TD226B—4CD | 66 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ64J-WJ | 64 | 400 | 115 | 12.8 | TD226B—6CD | 99 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ75J-WJ | 75 | 400 | 135 | 16 | TD226B—6CD | 99 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ90J-WJ | 90 | 400 | 163 | 18 | TBD226B—6CD | 132 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ100J-WJ | 100 | 400 | 181 | 20 | TBD226B—6CD | 132 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ120J-WJ | 120 | 400 | 217 | 24 | TBD226B—6CD5 | 159.5 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ24J-WF | 24 | 400 | 43.5 | 4.8 | D226B—3CD | 33 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ30J-WF | 30 | 400 | 54 | 5.9 | TD226B—3CD | 44 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ40J-WF | 40 | 400 | 72 | 7.9 | TD226B—4CD | 66 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ50J-WF | 50 | 400 | 90 | 9.9 | TD226B—4CD | 66 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ64J-WF | 64 | 400 | 115 | 12.8 | TD226B—6CD | 99 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ75J-WF | 75 | 400 | 135 | 16 | TD226B—6CD | 99 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ90J-WF | 90 | 400 | 163 | 18 | TBD226B—6CD | 132 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ100J-WF | 100 | 400 | 181 | 20 | TBD226B—6CD | 132 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| CCFJ120J-WF | 120 | 400 | 217 | 24 | TBD226B—6CD5 | 145 | 1500 | Mechanical | Electrical | Dual-circulate water-cool |
| Type | Water cooling, in-line, 4 stroke, humid cylinder liner |
| Cylinder numbers | 3/4/6 |
| Displacement(L) | 3.12/4.16/6.23 |
| Intake method | Natural aspirated, turbocharged or turbocharged inter cooled |
| Bore/stroke(mm) | 105/120 |
| Oil consumption(g/kW.h) | ≤1.36 |
| Min fuel consumption(g/kW.h) | ≤196 |
| Stable governing rate | ≤5% |
| Starting method | By electric |
| Noise dB(A) | ≤97 |
| Smoke(Rb) | ≤1.0 |
| Lubricating method | Forced Lubricating |
| Cooling method | Forced dual-circulation water cooling |
