Specifications
B504 series inverter adopts DSP control system which supplies Sensorless Vector Control(SVC).Detailed Product Description
Variable Frequency Drive:single or 3 phase, PID Control Function , Up to 25 fault protections ,Automatic Voltage Regulation (AVR) Function, multi-step speed, multiple torque setting source, output freq.0.1-600Hz
The combination of multi- modes and switching between different modes can be realized.
B504 Economic sensorless vector control inverter :
Power Range:
Single phase 220V 0.5HP-3HP (0.4KW-2.2KW)
Three phase 400V 1HP-3HP (0.75KW-2.2KW)
B504 series |
20005 |
2001 |
2002 |
2003 |
4001 |
4002 |
4003 |
Voltage |
1φ200V-240V |
3φ380V-440V |
|||||
Capacity(KW) |
0.4 |
0.75 |
1.5 |
2.2 |
0.75 |
1.5 |
2.2 |
Rated output vol.(V) |
3φ 220V-240V |
3φ 380V-440V |
|||||
Rated output current A |
3 |
4.5 |
7.0 |
10 |
2.5 |
3.7 |
5 |
Control mode |
Sensorless Vector Control (SVC), V/F Control |
||||||
Output frequency range |
Maximum 600Hz |
||||||
Frequency resolution |
Analog input volume:0.1Hz |
||||||
Overloading capacity |
Rated output current 150%-1 minute 180%-10 seconds |
||||||
Transmitter signal |
0~10mA,4~20mA,0~20mA |
||||||
No.of V/F Patterns |
Vector curve, Random V/F curve |
||||||
Location |
Indoor(protected from corrosive gases and dust) |
||||||
Ambient temperature |
-10~40°C(If beyond the allowable degree,one degree will Derogate 5% output current) |
||||||
Storage temperature |
-40~60°C |
||||||
Environmental temperature |
95%(without dew gather) |
||||||
Vibration |
2M/S2 (0.2G) |
||||||
Protection rate |
IP20 |
||||||
