291 FPV Kit 2km Long Range Video Camera With Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine

291 FPV Kit 2km Long Range Video Camera With Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine thumbnail-1
291 FPV Kit 2km Long Range Video Camera With Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine photo-1
US$ 1 - 45 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Type:
Airplane
Power:
Battery
Material:
Other, 5.8g tx module
Contact Supplier Request Quote Chat Now
Shenzhen Aoweishi Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Airplane
Power Battery
Material Other, 5.8g tx module
Scale Other, N
Radio Control Style RC Hobby
Place of Origin Guangdong, China
Brand Name Flysight
Model Number CM100T video camera wireless transmitter

291 FPV Kit! 2km Long Range Video Camera with Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine



Features of Combination of RC FPV Video Camera and 5.8G 200mW Wireless Transmitter:
Super light and super mini camera:
9.5X9.5X12mm
4Gram only of the combination of FPV Camera and 5.8G 200mW Transmitter
High definition micro CCTV camera,520TVL
0.008lux,can view clearly in almost complete darkness
Double lens-day&night offered


Ultra Light and Mini FPV Video Camera
SENSOR :1/3  CMOS
SYSTEM:   NTSC:656×492   PAL:768×576
HORIZONTAL RESOLUTION:520TVL
Exellent night vision of 0.008Lux/F1.2
LENS & VIEW ANGLE :0.5mm F2.0 / 55 °
Dimensions(LXWXH):9.5 x 9.5 x 12mm (smallest)
POWER SUPPLY: DC3.3-6V  70mA
VIDEO OUT:1.0V p-p/75ohm



5.8G 200mW Wireless transmitter:
Transmitter frequency:5725-5865MHz;  8 channels
Transmitting power:23dBm /200mW
Transmitting distance:>2000 metres
Frequency control:built-in frequency and phase lock loop
AV input:analog AV signal input
Power supply voltage:3.3V(don't use 5V)
Supply current:320mA
Dimension:19*19*3mm

291 FPV Kit 2km Long Range Video Camera with Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine291 FPV Kit 2km Long Range Video Camera with Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine291 FPV Kit 2km Long Range Video Camera with Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine291 FPV Kit 2km Long Range Video Camera with Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine291 FPV Kit 2km Long Range Video Camera with Wireless Transmitter Module 5.8 GHz for Model Aircraft Engine

FPV Kit Contents

1.1x Micro FPV Camera

2.1x Daylight Lens

3.1x Night time Lens

4.1x Micro 5.8Ghz Transmitter with built in antenna

5.1x RCA Video Cable set





How to change the FPV transmitter channels?



The channels can be selected or changed on your transmitter module by soldering jumpers between the Channel 1, 2, and 3 pins and ground as described below.



  • Ch1 pin + Ch2 pin + Ch3 pin connect to ground (Channel 1 - 5.705 gHz)
  • Ch2 pin + Ch3 pin connect to ground (Channel 2 - 5.685 gHz)
  • Ch1 pin + Ch3 pin connect to ground (Channel 3 - 5.665 gHz)
  • Ch1 pin + Ch2 pin connect to ground (Channel 5 - 5.885 gHz)
  • Ch3 pin connect to ground (Channel 4 - 5.645 gHz)
  • Ch2 pin connect to ground (Channel 6 - 5.905 gHz)
  • Ch1 pin connect to ground (Channel 7 - 5.925 gHz)
  • DEFAULT - no connect to ground (Channel 8 - 5.945 gHz)
