Working Principle:
1, Thermoforming:
The PVC/PE film into the forming area after preheating mold -- > forming mold blowing mold -- >blow film forming.
triangle knife cutting process and dotted line.
2, Filling:
6 filling heads, forming suppository for one-time embedded type filling, filling accuracy + / - 2%, material barrel has electric heating insulation system, with stirring motor at the top to make the drug in a uniform state, material barrel pump into the drugs by the high precision of filling head, filling a residual drugs through the other end of the cycle to the raw material filling barrel again next time.
3, Cooling:
Drugs into the cooling racks after the whole filled, external cooling box is equipped with water chiller, cooling air through the cooling box of four condenser suppository of cooling rack to cool.
sealing and part code:
4. Sealing and Cutting:
After cooling of the solid suppository into the sealing area: preheating mold -- -- > the sealing mould -- - > code mold. And then to shear a set of finished product for 5 and 6 grain (be) according to customer's requirements.
Feature:
Using inset filling,accurate in position, non-dribbling drug, non-hanging wall, high precise in counting.
Be wide in suitability, can be used to fill high gluing degree gelatin group and the traditional Chinese medicine ware.
Using PLC written formula control and industry grade person-machine inerface operation , possessing characteristics of high degree autoimmunization convenience in adjustment high precise thermo-control reliability in action and steady in running etc.
Having big volume storing fluid vessel, laying homoeothermic stirring and fluid surface auto control assembly.
Relieving worker’s physical labor strength for lower position of filling drug fluid, laying cycling to supply fluid and keeping thermo equipment of channel pathways, and it will ensure drug fluid not be coagulated when machine stop.
One side operation and better sight.
Technical parameters:
output |
6000—25000granules/hr |
single dosage |
0.5—5ml |
dosage allowed |
<±2% |
Suppository application form |
Bullet-head form, torpedo form, duck-mouth form and other special forms |
used to the host |
Synthesis of glycerin fatty acids, glycerin gelatin, polyethylene glycol etc. |
store the capacity of the liquid barrel |
50L |
working atmospheric pressure |
0.6Mpa |
consumption gas/minute |
1.5m3 |
used water quantity |
30kg /hr(cycle using) |
the voltage of the power |
The three phase AC 380V |
total power |
7.5KW |
external dimension |
3070mm×3480mm×1500mm |
total weight |
2000kg |
