GYTA33 underwater fiber optic cable
Cable Features
- Jelly filled and fiber contained loose tube
- PP filler (if necessary),
- steel wire central strength member
- co-polymer aluminium tape,
- PE inner sheath,
- armored with a layer of steel wires,
- outer PE sheath
Application
The special Cable Construction especially suitable for underwater/ Directly burialinstallations
Cable Parameter
| Optical Characteristics: | ||||
| Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
| A1b:62.5/125 | ||||
| Singlemode | G.652(A,B,C) | B1.1:Conventional fiber | ||
| G.652D | B2: Zero dispersion shifted | |||
| G.655 | B1.2 :Cut-off wavelength shifted | |||
| G.657(A1,A2 ,B3) | B4: Main technical data for positive | |||
| dispersion shifted single-mode fiber | ||||
Note:
3. Specially designed Cable structure is available on request.
Photo show:
| Packing Details | ||||||||||
| Standard Packaging | Reeled by wooden Drum suitable for long-distance shipment | |||||||||
| Normal cable factory length | Standard delivery length is 3000m with a tolerance of 5% or other required |
|||||||||
| Cable Weight | Approx. 310kg/km ~550kg/km | |||||||||
| Sheath Marking |
Cable type, Fiber Counts, Name of Manufacturer, Year of Manufacturing, Cable Length in meter |
|||||||||
1. Shipping: By sea or air due to heavy weight. Samples will be send by DHL, Fedex. etc
2. Payment: We accept T/T, L/C and Western Union, just choose what you like
3. Delivery time: Generally 3~7 working days upon receipt deposit. According to the quantity.
4. MOQ: Generally our MOQ is 1000meters. samples below 1meter can be provided freely
Quote Request Information
1. Fiber Count: 2 to 144 Fibers
2. Fiber type: Single mode: G652D, G655,G657. Multimode: 50/125,62.5/125. OM3
3. Order Quantity
Hunan guanglian photoelectricity technologies Co.,Ltd is the professional enterprise on fiher optical cable at widely range of outdoor fiber optic / aerial fiber optic cable / duct fiber optic cable /directly buried fiber optical cable /Adss and OPGW for power system transmmision.
1. The Gate of Factory
2. Raw Material
3. Production Line
4. Fiber Optic Cable Testing
Mechanical testing of Optical Fibre Cables is done to determine the quality of the Optical Fiber Cable, mechanical characteristics can be tested on testing machine for the particular test.
5. Wooden Drums
♦ We are the one of biggest manufacture of fiber optic cable in China and has more than 10 years manufacturing and selling experience.
♦ We accept OEM. The cable size and material are customized.Ur own logo and
own design are welcome. We will produce according to ur requirment and description;
♦ Please send us inquiry for more products info and we will give you feedback in 12 hours.
