Specifications
Woven type, glass non-alkali fiberglass tapethickness:
0.1mm-0.25mm
width:10-150mm
E glass non-alkali fiberglass insulation tape
thickness: 0.1mm-0.25mm
width:10-150mm
Production:
Fiberglass tape is made of nonalkali glassfiber yarn. It is woven by twisted
strands of fiberglass at right angles to one another, having the highest glass-resin ratio and mechnical strength of all fiberglass insulaiton materials.
Chemical components : oxidation potassium, oxidation sodium.
Featurers:
Good thermal resistance
Nice corrosion resistance
Best mechnical trength
Applications:
Banding and reinforcing insulaiton materials for motors, transformers and calbles.
Thickness |
0.10mm, 0.13mm, 0.15mm, 0.20mm,0.25mm etc |
Width |
10mm, 15mm, 20mm, 25mm, 30mm, 50mm,,,100mm |
Length |
30m, 50m, 200m, |
Density |
Warp 27 +/-1 strand/cm |
Weft |
15 +/-1 strand/cm |
Tensile strength |
400N/20mm |
