Model DSHX 3600H X-ray Fluorescence Spectrometer

Model DSHX 3600H X-ray Fluorescence Spectrometer thumbnail-1
Model DSHX 3600H X-ray Fluorescence Spectrometer photo-1
US$ 100 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Dshing
Model Number:
DSHX 3600H
Contact Supplier Request Quote Chat Now
Dshing Instrument Co., Ltd.(Zhuhai)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name Dshing
Model Number DSHX 3600H

Specifications

X-ray Fluorescence Spectrometer
1,high accuracy
2,easy to operate
3, high quality

Model DSHX 3600H X-ray Fluorescence Spectrometer

DSHX 3600H X-ray Fluorescence Spectrometer





I. Instrument introduction

1. The halogen - free plan with the new round environmental protection tide is the afforested policy which is greatly promoted by International Green and Peaceful Organization and supported by numerous international environmental protection organizations and international large-scale companies. The European Union 2002/95/EC Instruction, “Montreal Protocol”, “the Stockholm Treaty” and the board material laws and regulations of National Electrician Committee (IEC) have restricted on the halogen material. And, IEC 61249-2-21 in IEC laws and regulations stipulates that the maximum limit of chlorine, bromine and the overall halogen is: bromine and chlorine is less than 900ppm respectively; (bromine + chlorine) is less than 1500ppm.



2. Zhuhai Dshing Import&Export Co.,Ltd specializes in high-performance X-ray Fluorescence Spectrometers in the world. DSHX3600H, desktop, Non-halogen analysis spectrometer, introduced in 2009, is of high performance and high-technology halogen testing instrument. The technology, adopting the worldwide leading non-halogen analysis technology, equipped with the best intelligent vacuum system for non-halogen testing and using low energy X-ray to excite light element, thus solve testing problem of chlorine and bromine. The instrument can detect any products containing hazardous substance halogen. In addition, it can be used in all element and RoHS analysis. The instrument is of multi-functional and can meet the international newest standard.



II. Performance characteristics

1. Made in USA, halogen testing, X-ray tube of high efficient; the specification reaches the international advanced level.

2. Special accessories are developed for testing halogen element (especially chlorine element)

3. S100 detector, excellent energy linearity, energy resolution and energy spectrum characteristics. Higher peak-to-background ratio.

4. Dshing instrument patent product- Signal-Noise-Enhancer (SNE) improves the signal processing ability up to 25 times.

5. Low energy X-rays are used, delivering good results when exciting light elements such as CI, Br.

6. Intelligent pumping vacuum system; shield air influence and enlarge testing scope.

7. Auto spectrum stabilizer ensures the instrument working.

8. High SNR electronic circuit unit

9. Auto collimator and filter switch, exempt from trouble by manual.

10. Spectrum unfolding technology decomposes the spectrum peak; ensuring CI, Br and other light elements testing have the equal analysis accuracy.

11. Multiple linear regression, reducing the inter elemental absorption and enhancement effect

12. In-built CCD with high resolution

13. LCD makes the important parameter (tube voltage, tube current, vacuum) of the instrument obvious.



III. Technical specifications

1. Measurable elements: Na to U.

2. Element contents: 1ppm - 99.99%

3. Ability of simultaneous analysis: Simultaneously analysis of 24 elements.

4. Plating thickness: up to 0.005um each layer; it is able to analyze plating with more than 3 layers.

5. Analysis accuracy: 0.05%

6. Measurement time: 60s-200s

7. Energy resolution: (150±5)eV

8. Tube voltage: 5KV-50KV

9. Tube current: 50uA-1000uA

10. Forms of samples: powder, solid and liquid



IV. Standard configurations

1. Halogen testing, X-ray tube of high efficiency.

2. S100 detector

3. Signal-Noise-Enhancer SNE

4. Special accessories for halogen testing

5. Light path enhancement system

6. High SNR electronic circuit unit

7. In-built high resolution CCD

8. Automatic collimator and filter switch

9. Auto spectrum stabilizer

10. Triple safety protection model

11. Independent matrix effect correction model

12. Multi-variable non-linear regression procedure

13. Overall steel support structure

14. 90mm*70mm LCD



V. Application fields

Non-halogen testing; All element analysis; RoHS testing; Plating thickness.
