ASME SB 338 Grade 2 titanium tube
1. Material: pure titanium Gr2
2 . Standards: ASTM B861, ASTM B337, ASTM B338
3. Common sizes:
OD12.7*WT0.55mm
OD15.88*WT0.89mm
OD19.05*0.9mm
OD25*WT1.5mm
OD25*WT2mm
OD38*WT2mm
other size are available to us
4. Application: electronics , heat exchanger and condenser
5. Package: plastic bag inside, standard export box outside
Chemical composition:
Grades |
N |
C |
H |
Fe |
O |
Al |
V |
Pd |
Mo |
Ni |
Gr 1 |
0.03 |
0.08 |
0.015 |
0.20 |
0.18 |
/ |
/ |
/ |
/ |
/ |
Gr 2 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
/ |
/ |
Gr 3 |
0.05 |
0.08 |
0.015 |
0.30 |
0.35 |
/ |
/ |
/ |
/ |
/ |
Gr 7 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
0.12~0.25 |
/ |
/ |
Gr 9 |
0.03 |
0.08 |
0.015 |
0.25 |
0.15 |
2.5~3.5 |
2.0~3.0 |
/ |
/ |
/ |
Gr12 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
0.2~0.4 |
0.6~0.9 |
Physical properties:
Material |
Tensile strength(MPa) |
Yield strength(MPa) |
Elongation(%) |
Gr1 (CP1 Titanium, Low oxygen) |
≥240 |
≥138 |
≥24 |
Gr2 (CP2 Titanium, standard Oxygen) |
≥345 |
≥275 |
≥20 |
Gr3 (CP3 Titanium, standard Oxygen) |
≥450 |
≥380 |
≥18 |
Gr7 (Titanium, 0.12-0.25%Pd) |
≥345 |
≥275 |
≥15 |
Gr9 (Ti-3Al-2.5V) |
≥620 |
≥483 |
≥10 |
Gr11(Ti-Pd0.12-0.25%, Low Oxygen) |
≥240 |
≥138 |
≥24 |
Gr12(Ti-Mo-Ni) |
≥483 |
≥345 |
≥18 |
Gr16(Ti+Pd0.04-0.08%, Standard Oxygen) |
≥345 |
≥275 |
≥20 |
Gr17(Ti+Pd0.04-0.08%, Low Oxygen) |
≥240 |
≥138 |
≥24 |
