New Style Low Cost 12psbg 12PSB Fuel Diesel Injection Pump Test Bench Repair Workshop Tool

Name: New Style Low Cost 12psbg 12PSB Fuel Diesel Injection Pump Test Bench Repair Workshop Tool
Brand: JHDS
SKU: 125512145

US$ 2,700 - 12,000 MOQ: 1 Set

Key Specifications

Type:

Engine Analyzer

Voltage:

380V,220V

Power:

7.5-45KW

Taian Jinhai Dongshan Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Engine Analyzer

Voltage 380V,220V

Power 7.5-45KW

Certification CE,ISO

Applicable Models Mechanical pump

Place of Origin Shandong, China

Brand Name JHDS

Model Number 12 PSB JHDS-5

Warranty 1 Years

new style low cost 12psbg 12PSB fuel diesel injection pump test bench repair workshop tool

Product Description

Parameters

JHDS-5 Industrial Computer Type Test Bench			7.5KW	11KW	15KW	18.5KW
1	Rotation speed range of main shaft(rpm)		0-4000	0-3000	0-3000	0-3000
2	Motor output power(KW)		7.5	11	15	18.5
3	Pump output power(KW)		0.75	0.75	0.75	1.1
4	Height from center line of main shaft to work table(mm)		125	125	125	125
5	Rotation direction of main shaft		Positive Negative	Positive Negative	Positive Negative	Positive Negative
6	Testable cylinders of injection pump		12	12	12	12
7	Standard model of fuel injector		.
8	Oil injection count range		0-1000	0-1000	0-1000	0-1000
9	Capacity of oil tank(L)		>50	>50	>50	>50
10	Pressure of fuel system	High	0-4	0-4	0-4	0-4
10	Pressure of fuel system	Low	0-0.4	0-0.4	0-0.4	0-0.4
11	Supply oil capacity(L/min)		>10	>10	>10	>10
12	Temperature of fuel(°c)		40±2	40±2	40±2	40±2
13	Precise of fuel filter(μ)		5	5	5	5
14	Capacity of measuring cup(ml)		45/150	45/150	45/150	45/150
15	Pressure of air way (Mpa)	Positive	0-0.3	0-0.3	0-0.3	0-0.3
16	Pressure of air way (Mpa)	Negative	-0.05-0	-0.05-0	-0.05-0	-0.05-0
17	DC voltage(V)		12/1824	12/24	12/24	12/24
18	Package dimension(m)(L×W×H)		2.2×1.15×1.8	2.2×1.15×1.8	2.2×1.15×1.8	2.4×1.2×1.8
19	Weight(Kg)		900	900	1050	1050
