Using SunRack,Enjoy Sunshine
-------------A leading solar mounting expert
1.Specification for tile roof solar mounting system
| Mounts Type | tile roof solar mounting system |
| Installation Site | pitched roof |
| Applicable Roof Cladding | Suitable for mounttypes of cladding |
| Roof Slope | Up to 60 degree |
| Max.Building Height | Up to 20m |
| Wind Load | 60m/s |
| Snow Load | 1.4 kn/m2 |
| Applicable Module | Framed or framelss |
| Module Orientation | Landscape or portrait |
| Design Standard | AS/NZS1170 |
| Material | Al6005-T5,SS304 |
| Warranty | 10 years warranty and 25 years service time |
2.Case of solar roof tile hook pv panel mounting structure
3.Related products------ solar module mounting structure
4.Factory
5.Certification of solar mounting brackets
6.Package of SunRack solar mounting system
7.Solar EXPO(2015 Sunforson Show Time coming)
1 PV EXPO 2015,held in Tokyo,Japan,on Feb 25~27th,2015
2 SNEC 2015 PV POWER EXPO,will be held at Shanghai,China,on April 28~30th,2015
3 SOLAR POWER INTERNATIONAL 2015,will be held at Los Angeles, United States, on September 15~17th,2015
4 THE GREEN EXPO 2015,will be held at Mexico City, on September 23th~25th,2015
Necessary info. for us to design and quote
•What is your pv panels dimension?_____mm Length x_____mm Width x____mm Thickness
•How many panel are you going to mount? _______Nos.
•What kind of roof do you have?__________(Tin/metal/tile/slate/shingle roof)
•What is your planned pv assmebly block? ________Nos. in a row
•How is weather there,such as wind speed and snow load?___m/s anit-wind speed and____KN/m2 snow load.
