MATRIX QUATTRO 24/192 Balanced USB DAC& Head AMP &Remote
Product Description:
QUATTRO DAC is a combination of high-speed digital signal processing technology, multi-D / A converters, with a variety of input and output ports can be used with a variety of devices.
QUATTRO audio system through careful circuit design, high quality devices use, professional-grade playback, the traditional audio equipment to a new height.
MATRIX QUATTRO DAC with top AD1853 24Bit/192kHz D / A conversion unit, fully balanced architecture. Oversampling unit within the ASRC, with MATRIX CPLD unique algorithm can effectively reduce the input signal jitter, four high-speed signal PCB layout, sophisticated design QUATTRO DAC has the following features:
• Low Jitter rate with a professional digital receiver chip and independent clock.
• has a fiber optic, coaxial, USB, AES / EBU and analog inputs and a variety of input methods, and automatic detection of input.
• USB supports up to 24BIT/96kHz sample input, other input port supports up to 24BIT/192kHz sampling.
• Automatic de-emphasis, can be automatically 32,44.1,48,96 K sampling rate signal for automatic de-emphasis control.
• Internal high-speed CLPD XILINX MATRIX has its own algorithm, sampling rate boost circuit with ASRC reduce jitter.
• analog with balanced and unbalanced outputs can be connected to different interfaces.
• High-quality LME49600 headphone amplifier unit can easily drive up to 600 Euro impedance headphones.
• digital input port with ESD static protection and transformer isolation protection.
• Analog output with low distortion audio-specific op-amp LM4562, to get the best signal playback.
• High-quality audio NORATEL dedicated toroidal transformer, the circuit unit with an independent multi-level power supply.
• High-quality NEUTRIK audio connectors.
• High-quality ALPS volume potentiometer.
• Multi-voltage compatible design.
• with infrared remote control.
• natural sound performance with texture, ultra-high resolving power and signal to noise ratio for you to discover the music every minute detail. Fully meet your high-quality Hi-Fi audio needs.
Parameter:
Input port :
| Optical interface |
shielded optical digital input Sampling rate support 24Bit 32kHz-192kHz |
| BNC coaxial connector |
BNC 75 ohm impedance Sampling rate support 24Bit 32kHz-192kHz |
| USB interface |
USB-B Interface Sampling rate support 24Bit 44.1kHz-96kHz |
| AES / EBU |
XLR 110 ohms impedance Sampling rate support 24Bit 32kHz-192kHz |
| Analog Input | RCA terminal 20Hz-20kHz 47kOhms Lotus |
Output:
| RCA connector Output level | 0V-2.0V adjustable |
| XLR connectors output level | 0V-4.0V adjustable (XLR interface definition: 1 = ground, 2 = hot, 3 = cold) |
| Frequency response | 20Hz-20KHz |
| Signal to noise ratio | 114dB |
| Dynamic Range | 110dB |
| Distortion | <0.00056% (1kHz) |
Headphone Amplifier:
| Output impedance | <0.11 Ohms |
| Maximum output current | <0.11 Ohms |
| Gain Bandwidth | > 500kHz |
| Signal to noise ratio | 106dB |
| Distortion | <0.0005% |
Power requirements:
| Power | AC 220V-240V 50/60Hz (AC 110V-120V 50/60Hz) |
| Working power consumption | <25W |
| Standby power consumption | <2W |
Other specifications:
| Operating temperature | 0 - +40 °C |
| Weight | 2.0kg |
| Size | 205 × 245 × 44 (L × W × H) |
| Fuse size | 5 × 20mm 250V 0.5A |
Note: I have 110V and 220V version,please told me when you order it.
1.Voltage
Can you change the voltage and plug?Our voltage is 110V or 220V,and our plug is EU,US or others.
Yes,we will change the voltage and plug according to your shipping address.
2.RMA
Hi seller,I bought one device from your shop before,but it is broken now under warranty,can you help me repair it?
Yes,please send the defective device or wrong device to our Chinese address(please contact our salesman).
Once we received it,we will send you the new replacement or refund immediately.
3.Warranty
I bought your product 7 years ago,but it's broken now,can you repair it?
Oh...Dear friend,our warranty is 1 year,would you like have a try of the newest one?
4.Samples
Hi,man,I love your products too much,can you send me a sample to test?I will place big order in future.
Hi,my friend,we can send you sample,and the sample charge is lower than the retail price.
5.Shenzhen Shop
Hi,brother,I am going to Shenzhen,China,can I visit your shop?
Yes,my friend,welcome to our shop,you can have a try of your favorite devices,and it would be better if you could inform me in advance,so I can prepare for your needed devices.
Shop address: 4F9,No.3018,Gume,Wanshang Electric City,Huaqiang north road,Futian zone.Shenzhen,China.
