Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > CH-50 Paddle Type Powder Mixer

CH-50 Paddle Type Powder Mixer

Name: CH-50 Paddle Type Powder Mixer
Brand: NOAH
SKU: 126018235

CH-50 Paddle Type Powder Mixer thumbnail-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Mixer Type:

Paddle

Product Type:

Other, Pharmaceutical, Food, Chemical

Contact Supplier Request Quote Chat Now

Shenzhen Nuoya Pharmaceutical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Shenzhen Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Mixer Type Paddle

Product Type Other, Pharmaceutical, Food, Chemical

Application Other, Powder, Mixer

Additional Capabilities Other, mixing machine

Place of Origin Guangdong, China

Brand Name NOAH

Model Number CH-50

Max. Loading Capacity 30L

Voltage 380V

Power(W) 1500

Dimension(L*W*H) 1200*520*1000mm

Certification CE, ISO9001 , CE

Warranty One Year

After-sales Service Provided Engineers available to service machinery overseas

CH-50 Paddle Type Powder Mixer

Product Description

Main Application
As a whole stainless horizontal tank type mixer, this machine is widely used for mixing of powdery or paste material in pharmaceutical chemical and foodstuff industries.

Working Principle
S type agitiating paddle is rotated, through mechanical driving, which pushes the material turn repeatedly and mix uniformly. Operate with electrical control, it can set mixing time to realize automatic stop and electric discharge upon expiration, thus improving the mix quality of each batch of material and realizing the high homogeneous mixing.

Technical parameters

ITEM	TYPE
ITEM	CH10	CH50	CH100	CH150	CH200
Trough capacity L	10	50	100	150	200
Miaing arm speed r/min	25	24	24	24	24
Tilting angle of the trough	105	105	105	105	105
Main motor KW	0.37	1.5	2.2	3	3
Overall dimension mm	550250540	*12005201000*	13806851125	14806851125	16607001200
Net weight kg	65	120	200	250	300

Packaging & Shipping

Export standard plywood package are supplied with well packed. we can make the packages according to customer's request. Sea packages or Air packages are both available.
Usually to ship CH-50 Paddle Type Powder Mixer by sea way.

Company Information

About us:

Nuoya Machinery Company is one famous group and apply itself to R&D and manufacture machinery for Pharmaceutical, Chemical, food and so etc fields.

The Main products are: Tablet press, Mixer, Crusher, Granulator, Dryer, Coater, Packing machine….we also can make punch die sets and spare parts in standard or not standard.

our company has initiatively fetch in the advanced processing equipments and technologies since established, constantly collected qualified talents and strengthened the internal management. Our production, examination and supervision are strictly following the ISO9001 international quality system. Owing to high quality, beautiful appearance, warm service and reasonable price, Nuoya products have earned high confidence and reputation in the International market. Currently, Products have sold to America, Australia, Canada, Germany, New Zealand, Russia, dozens of countries and regions.

FAQ

In order to help client choose suitable machine model and help us service for you better, please kindly provide below information. Thanks in advance.

1).What kind of products will be mixed: our mixing machine can mix dry powder or granules, or paste material or mixing powder which needs to add liquid.

2).The mixing material is dry or wet?

3).Required production capacity.
