XZS500 Vibration screening machine
Applications:
1.Our XZS500 Vibration screening machine/XZS Whirlpool vibration sieve machine consists of hopper, vibration chamber and coupling and motor. There are eccentric wheel, rubber soft parts, and main shaft bearings.
2.The adjustable centric weight can drive the central line of main shaft through motor under the unstable state. It produces centrifugal force that makes raw materials from vortex in the sieve.
3.The size of amplitude of eccentric weight can be regulated in accordance with the different raw materials. The features of the machine are compact in structure, small in size, free of dust and with little noise. Also it is highly efficient and low energy consuming, easy of move and maintenance.
Main technical specifications:
Type |
XZS500 |
Output |
100-300kg/h |
Screen mesh |
12-200 |
Screen diameter |
500mm |
Power |
0.75kW |
Overall size |
700 x 1200mm |
Net weight |
180kg |
Adjustment of vibrating range |
1-6mm |
Each model is provided with double or triple outlets | |
XZS Whirlpool vibration sieve machine / vibration screening machine / round vibration sieve machine )
