Specifications
50L Hermetic Water Cooling Circulating Oil Bath1.Room temperature to 250 Degree
2.Max flow: 30L/min
3.Power:250W
High temperature to 250 Degree 100L Hermetic Water Cooling Circulating Oil Bath for 100L Stainless Steel Reactors
Introduction:
Provide heat source for all kinds of devices need to be heated. Can be used alone and also can be used with Rotary Evaporators and Reaction Kettles. There are water bath, oil bath, circulating water bath, circulating oil bath, air cooling circulating water bath, air cooling circulating oil bath and other types which can be chosen according to the needs.
Characteristics:
1. Containers are made of good quality stainless steel and can resist corrosion.
2. Control temperature by digital display, controlled by PID, with high precision of temperature control and easy to operate .
3. Vertical structure, be furnished with truckles, which is convenient for moving.
4. High performance circulating pumps of circulating water bath and circulating oil bath can provide output loops and provide homoiothermic heat source for reaction kettles.
5. Watercooling circulating water bath and air cooling circulating oil bath can achieve fast cooling by using water from cooling tower.
Parameters of High temperature to 250 Degree 100L Hermetic Water Cooling Circulating Oil Bath
Product |
Hermetic Water Cooling Circulating Oil Bath |
|
Model |
SY-100-250 |
|
Temperature range |
Room temperature~250°C |
|
Ambient temperature |
5~40°C |
|
Ambient humidity |
≤60% |
|
Power supply |
380V±10% 50HZ |
|
Power of heater strip |
12kw |
|
Circulating pump |
Power |
750W |
Max flow |
85L/min |
|
Max lift |
25m |
|
Material of bath |
SUS304 |
|
Material of transmission pipeline and valve |
SUS304 |
|
Dimension |
About 820L×735W×1468Hmm |
|
Weight |
About 100kg |
|
Advantages compared with Air Cooling Circulating Oil Bath:
1. when you use water cooling circulating oil bath, you have a cooling tower in advance.
2. Water cooling circulating oil bath uses water from cooling tower and can't be affected by environment, so it is more stable to cooling equipments and better performance.
3. Water cooling circulating oil bath can keep temperature constant, but air cooling circulating oil bath can't.
Recommended Total System:
Circulating Water Vacuum Pump + Glass Reactor + Water Cooling Circulating Oil Bath
ISO9001:2008 Certificate:
Fairs:
Welcome to our factory:
