Aluminium Window Door Double Mitre Cutting Saw Machine--PARKER

Aluminium Window Door Double Mitre Cutting Saw Machine--PARKER thumbnail-1
Aluminium Window Door Double Mitre Cutting Saw Machine--PARKER photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
PARKER
Model Number:
LJZ2-500*4200
Contact Supplier Request Quote Chat Now
Jinan Parker Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name PARKER
Model Number LJZ2-500*4200
Condition New
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Using hi-precision main shaft
Moving heads adopt imported linear bearing motion pair
aluminum saw cutting machine

 Aluminium Window Door Double Mitre Cutting Saw Machine

LJZ2-500*4200

Aluminium Window Door Double Mitre Cutting Saw Machine--PARKER



Feature:

♦ LJZ2S-500X4200 is used for cutting of Alu-alloy and PVC profile. The imported special hard-metal saw features the high precision and efficiency for cutting alu-alloy doors and windows. And the cutting precision has reached the advanced level in the world.

♦ The hi-precision main shaft makes the saw stable and the surface smooth. The gas-liquid damping cylinder realizes smooth feeding and steady moving. The automatically opening and closing protecting cover makes the operation safe and easy.

♦ The moving heads adopt imported linear bearing motion pair, and they features high precision. The moving feeder can efficiently locate the profile, and making the clamping easy and reliable. With the large saws and long structures, the saw has large cutting range.

♦ If CNC system is put in, it can make the cutting much more precise (precision 0.01mm), and the operating more visualized.





Parameter:

♦ Voltage:

380V   50HZ

♦ Power:

4.4KW

♦ Air pressure:

0.5-0.8MPa

♦ Air consumption:

200L/min

♦ Blade specification:

Φ500XΦ30X4.4 Z=120(standard size)

♦ Cutter moving speed:

0-2m/min

♦ Cutting length:

Max4000mm   Min200mm

♦ Cutting width:

Max.135mm

♦ Cutting height:

Max.300mm

♦ Cutting angle:

45°   90°

♦ Repeat locating length error:

±0.2mm

♦ Angle error

±4′

♦ Surface plainness:

±0.1mm

♦ Surface harshness:

Ra12.5μm

♦ Overall dimension:

5500mmX1750mmX1990mm
